Infiniti QX60 I facelift (2016-2021) throttle pos sens 2 Wiring diagrams

This page contains all the electrical diagrams for the component. throttle pos sens 2, in which he is found in the car Infiniti QX60 I facelift (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram throttle pos sens 2 (1 of 2)

Wiring diagram throttle pos sens 2 for Infiniti QX60 I facelift (2016-2021) (1 of 2)

Get access

ACCELERATOR PEDAL POSITION SENSOR APP SENS 1 APP SENS 1 APP SENS 2 ASCD STEERING SW BLK WIRE BLU WIRE BRAKE PEDAL POSITION SWITCH BRK PDL CAN L CAN-H COMPUTER DATA LINES SYSTEM ECM (LEFT SIDE OF ENGINE COMPT) FUSE 10 FUSE 30 FUSE 38 FUSE 46 FUSE 55 FUSE BLOCK (J/B) GRN WIRE HOT AT ALL TIMES HOT IN ON OR START HOT W/ ECM RELAY ENERGIZED IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LT GRN WIRE MTR PWR SPLY MTR RLY PNK WIRE RED WIRE SENS GND SENS GND (TPS) SENS PWR SPLY SENS PWR SPLY (TPS) SENSOR 1 SENSOR 2 STOP LAMP SW STOP LAMP SWITCH THROTTLE CONTROL MOTOR RELAY THROTTLE CTRL MTR (CLS) THROTTLE CTRL MTR (OPN) THROTTLE POS SENS 1 THROTTLE POS SENS 2 WHT WIRE YEL WIRE

Go to component -> Cruise control circuit, except hybrid (1 of 2) -> THROTTLE POS SENS 2

Wiring diagram throttle pos sens 2 (2 of 2)

Wiring diagram throttle pos sens 2 for Infiniti QX60 I facelift (2016-2021) (2 of 2)

Get access

ACCELERATOR PEDAL POSITION SENSOR APP SENS 2 ASCD STEERING SW BLK WIRE BLU WIRE BRAKE PEDAL POSITION SWITCH BRK PDL POS SW COMPUTER DATA LINES SYSTEM ECM (LEFT SIDE OF ENGINE COMPT) ECM GND FUSE 10 FUSE 30 FUSE 38 FUSE 46 FUSE 55 FUSE BLOCK (J/B) GRN WIRE HEV CAN-H HEV CAN-L HOT AT ALL TIMES HOT W/ ECM RELAY ENERGIZED HOT W/ IGNITION RELAY 1 ENERGIZED HOT W/ IGNITION RELAY-2 ENERGIZED HPCM IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LT BLU WIRE LT GRN WIRE MTR PWR SPLY MTR RLY PWR SPLY RED WIRE SENS GND SENS PWR SPLY SENS PWR SPLY APP SENS 1 SHIELD STOP LAMP SW STOP LAMP SWITCH THROTTLE CONTROL MOTOR RELAY THROTTLE CTRL MTR (CLS) THROTTLE CTRL MTR (OPN) THROTTLE POS SENS 1 THROTTLE POS SENS 2 WHT WIRE YEL WIRE

Go to component -> Cruise control circuit, hybrid (1 of 2) -> THROTTLE POS SENS 2
