Infiniti QX60 I facelift (2016-2021) taillamp relay Wiring diagram
This page shows the only wiring diagram for the component.taillamp relay, which is found in the car Infiniti QX60 I facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram taillamp relay (1 of 1)
BLK WIRE
BLU WIRE
BUZZER
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
ELECTRIC BRAKE
ELECTRIC BRAKE (PRE-WIRING)
EXCEPT HYBRID
FUSE 13
FUSE 31
FUSE 51
FUSE 52
FUSE BLOCK (J/B)
FUSIBLE LINK BOX (BATTERY)
FUSIBLE LINK C
FUSIBLE LINK D
GND CAN-L (SIG)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN
IGN 1 RLY
IGNITION RELAY 1
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LEFT "C" PILLAR)
LEFT LICENSE PLATE LAMP
LEFT REAR COMBINATION LAMP
LEFT TURN IND
LT GRN WIRE
NCA WIRE
PNK WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT LICENSE PLATE LAMP
RIGHT REAR COMBINATION LAMP
RIGHT TURN IND
SIDE MARKER
STOP
TAIL
TAIL (GREEN) IND
TAIL/L RLY
TAILLAMP RELAY
TAN WIRE
TRAILER RECEPTACLE
TRAILER)
TURN SIGNAL
UNIFIED METER CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (3 of 3) -> TAILLAMP RELAY
