Infiniti QX60 I facelift (2016-2021) shift lock solenoid out Wiring diagram
This page shows the only wiring diagram for the component.shift lock solenoid out, which is found in the car Infiniti QX60 I facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shift lock solenoid out (1 of 1)
3.5L, 2.5L HYBRID
AT DEVICE OUT
BATT PWR F/L
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRK SW LAMP
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
CVT SHIFT SELECTOR
EXCEPT HYBRID
FUSE 10
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK BOX 1
FUSE, FUSIBLE LINK, RELAY BOX 1
FUSIBLE LINK O
GND 2
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
PARK POSITION SWITCH
PARK POSITION SWITCH (SHIFT SELECTOR)
PNK WIRE
RIGHT END OF DASH)
SHIFT LOCK SOLENOID
SHIFT LOCK SOLENOID OUT
SHIFT P
STOP LAMP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> SHIFT LOCK SOLENOID OUT
