Infiniti QX60 I facelift (2016-2021) rse audio shield Wiring diagrams

This page contains all the electrical diagrams for the component. rse audio shield, in which he is found in the car Infiniti QX60 I facelift (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram rse audio shield (1 of 8)

Wiring diagram rse audio shield for Infiniti QX60 I facelift (2016-2021) (1 of 8)

Get access

AUX VIDEO - AV CONTROL UNIT BACK BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DISPLAY DISPLAY CONTROL UNIT ENTER F DVD OUT LH- F DVD OUT RH- F DVD OUT SHIELD GRN WIRE GRY WIRE ILL INPUT 1 INPUT 2 LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MENU DOWN MENU UP NOT USED PNK WIRE REAR SEAT ENTERTAINMENT CIRCUIT RED WIRE RSE AUDIO IN LH- RSE AUDIO IN RH- RSE AUDIO SHIELD SHIELD SOUND SYSTEMS SOURCE SPD 8 P/R STEERING COLUMN) STEERING SWITCHES TAN WIRE TEL TEL SHIELD TEL SIG IN- UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) USB D- USB GND VBUS VIDEO SHIELD VOLUME DOWN VOLUME UP WHT WIRE YEL WIRE

Go to component -> Navigation circuit, except hybrid w/ center point audio (5 of 7) -> RSE AUDIO SHIELD

Wiring diagram rse audio shield (2 of 8)

Wiring diagram rse audio shield for Infiniti QX60 I facelift (2016-2021) (2 of 8)

Get access

AUX VIDEO - AV CONTROL UNIT BACK BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CENTER SPEAKER COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DISPLAY DISPLAY CONTROL UNIT ENTER F DVD OUT LH- F DVD OUT RH- F DVD OUT SHIELD GRN WIRE GRY WIRE GUIDE VOICE SHIELD GUIDE VOICE- ILL INPUT 1 INPUT 2 LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MENU DOWN MENU UP NOT USED PNK WIRE REAR SEAT ENTERTAINMENT CIRCUIT RED WIRE RSE AUDIO IN LH- RSE AUDIO IN RH- RSE AUDIO SHIELD SHIELD SOUND SYSTEMS SOURCE SPD 8 P/R STEERING COLUMN) STEERING SWITCHES TAN WIRE TEL TEL SHIELD TEL SIG IN- UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) USB D- USB GND VBUS VIDEO SHIELD VOLUME DOWN VOLUME UP WHT WIRE YEL WIRE

Go to component -> Navigation circuit, except hybrid w/o center point audio (4 of 6) -> RSE AUDIO SHIELD

Wiring diagram rse audio shield (3 of 8)

Wiring diagram rse audio shield for Infiniti QX60 I facelift (2016-2021) (3 of 8)

Get access

AUX VIDEO - AV CONTROL UNIT BACK BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DISPLAY DISPLAY CONTROL UNIT ENTER F DVD OUT LH- F DVD OUT RH- F DVD OUT SHIELD GRN WIRE GRY WIRE ILL INPUT 1 INPUT 2 LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MENU DOWN MENU UP NOT USED PNK WIRE REAR SEAT ENTERTAINMENT CIRCUIT RED WIRE RSE AUDIO IN LH- RSE AUDIO IN RH- RSE AUDIO SHIELD SHIELD SOUND SYSTEMS SOURCE SPD 8 P/R STEERING COLUMN) STEERING SWITCHES TAN WIRE TEL TEL SHIELD TEL SIG IN- UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) USB D- USB GND VBUS VIDEO SHIELD VOLUME DOWN VOLUME UP WHT WIRE YEL WIRE

Go to component -> Navigation circuit, hybrid (5 of 7) -> RSE AUDIO SHIELD

Wiring diagram rse audio shield (4 of 8)

Wiring diagram rse audio shield for Infiniti QX60 I facelift (2016-2021) (4 of 8)

Get access

AUX VIDEO - AV CONTROL UNIT BACK BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DISPLAY DISPLAY CONTROL UNIT ENTER F DVD OUT LH- F DVD OUT RH- F DVD OUT SHIELD FUSE 65 FUSE, FUSIBLE LINK, RELAY BOX 2 GRN WIRE GRY WIRE GUIDE VOICE SHIELD GUIDE VOICE- HOT AT ALL TIMES ILL INPUT 1 INPUT 2 LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MENU DOWN MENU UP NOT USED PNK WIRE REAR SEAT ENTERTAINMENT CIRCUIT RED WIRE RSE AUDIO IN LH- RSE AUDIO IN RH- RSE AUDIO SHIELD SHIELD SOUND SYSTEMS SOURCE SPD 8 P/R STEERING COLUMN) STEERING SWITCHES TAN WIRE TEL TEL SHIELD TEL SIG IN- UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) USB D- USB GND VBUS VIDEO SHIELD VOLUME DOWN VOLUME UP WHT WIRE YEL WIRE

Go to component -> Radio circuit, except hybrid base (3 of 4) -> RSE AUDIO SHIELD

Wiring diagram rse audio shield (5 of 8)

Wiring diagram rse audio shield for Infiniti QX60 I facelift (2016-2021) (5 of 8)

Get access

AUX VIDEO - AV CONTROL UNIT BACK BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DISPLAY DISPLAY CONTROL UNIT ENTER F DVD OUT LH- F DVD OUT RH- F DVD OUT SHIELD GRN WIRE GRY WIRE ILL INPUT 1 INPUT 2 LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MENU DOWN MENU UP NOT USED PNK WIRE REAR SEAT ENTERTAINMENT CIRCUIT RED WIRE RSE AUDIO IN LH- RSE AUDIO IN RH- RSE AUDIO SHIELD SHIELD SOUND SYSTEMS SOURCE SPD 8 P/R STEERING COLUMN) STEERING SWITCHES TAN WIRE TEL TEL SHIELD TEL SIG IN- UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) USB D- USB GND VBUS VIDEO SHIELD VOLUME DOWN VOLUME UP WHT WIRE YEL WIRE

Go to component -> Radio circuit, except hybrid bose w/ center point audio (5 of 7) -> RSE AUDIO SHIELD

Wiring diagram rse audio shield (6 of 8)

Wiring diagram rse audio shield for Infiniti QX60 I facelift (2016-2021) (6 of 8)

Get access

AUX VIDEO - AV CONTROL UNIT BACK BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CENTER SPEAKER COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DISPLAY DISPLAY CONTROL UNIT ENTER F DVD OUT LH- F DVD OUT RH- F DVD OUT SHIELD GRN WIRE GRY WIRE GUIDE VOICE SHIELD GUIDE VOICE- ILL INPUT 1 INPUT 2 LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MENU DOWN MENU UP NOT USED PNK WIRE REAR SEAT ENTERTAINMENT CIRCUIT RED WIRE RSE AUDIO IN LH- RSE AUDIO IN RH- RSE AUDIO SHIELD SHIELD SOUND SYSTEMS SOURCE SPD 8 P/R STEERING COLUMN) STEERING SWITCHES TAN WIRE TEL TEL SHIELD TEL SIG IN- UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) USB D- USB GND VBUS VIDEO SHIELD VOLUME DOWN VOLUME UP WHT WIRE YEL WIRE

Go to component -> Radio circuit, except hybrid bose w/o center point audio (4 of 6) -> RSE AUDIO SHIELD

Wiring diagram rse audio shield (7 of 8)

Wiring diagram rse audio shield for Infiniti QX60 I facelift (2016-2021) (7 of 8)

Get access

AUX VIDEO - AV CONTROL UNIT BACK BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DISPLAY DISPLAY CONTROL UNIT ENTER F DVD OUT LH- F DVD OUT RH- F DVD OUT SHIELD GRN WIRE GRY WIRE ILL INPUT 1 INPUT 2 LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MENU DOWN MENU UP NOT USED PNK WIRE REAR SEAT ENTERTAINMENT CIRCUIT RED WIRE RSE AUDIO IN LH- RSE AUDIO IN RH- RSE AUDIO SHIELD SHIELD SOUND SYSTEMS SOURCE SPD 8 P/R STEERING COLUMN) STEERING SWITCHES TAN WIRE TEL TEL SHIELD TEL SIG IN- UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) USB D- USB GND VBUS VIDEO SHIELD VOLUME DOWN VOLUME UP WHT WIRE YEL WIRE

Go to component -> Radio circuit, hybrid (5 of 7) -> RSE AUDIO SHIELD

Wiring diagram rse audio shield (8 of 8)

Wiring diagram rse audio shield for Infiniti QX60 I facelift (2016-2021) (8 of 8)

Get access

ACC DET IN ACC DET OUT L ACC DET OUT R ACC RLY ACCESSORY RELAY 2 AV CONTROL UNIT AV GND AV GND L (A GND) AV GND R (A GND) BAT BCM BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE CAN L CAN-H COMP NAVI IN - COMPUTER DATA LINES SYSTEM CONNECTOR SHIELD CONT GND DIN EXCEPT HYBRID F DVD OUT LH- F DVD OUT RH- F DVD OUT SHIELD FUSE FUSE 1 FUSE 15 FUSE 65 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX 1 FUSE, FUSIBLE LINK, RELAY BOX 2 GND (L) GND 2 GND R CONT GRN WIRE GRY WIRE GUI SELECT 1 GUI SELECT 2 HOT AT ALL TIMES HYBRID EXCEPT HYBRID LEFT "C" PILLAR) LEFT HEADREST DISPLAY UNIT LH NAVI AUDIO + LH RR SRC OUT - LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L M-CAN 1 L IN NAVI DVD SHLD OUT PNK POWER DISTRIBUTION SYSTEM WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PWR GND RED WIRE RH NAVI AUDIO + RH RR SRC OUT - RIGHT END OF DASH) RSE AUDIO IN LH- RSE AUDIO IN RH- RSE AUDIO SHIELD SHIELD TAN WIRE VIDEO DISTRIBUTOR (UNDER CENTER CONSOLE) WHT WIRE YEL WIRE

Go to component -> Rear seat entertainment circuit (1 of 2) -> RSE AUDIO SHIELD
