Infiniti QX60 I facelift (2016-2021) right side curtain air bag module Wiring diagram
This page shows the only wiring diagram for the component.right side curtain air bag module, which is found in the car Infiniti QX60 I facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right side curtain air bag module (1 of 1)
ACT VENT-
AIR BAG DIAGNOSIS SENSOR UNIT
AIR BAG IND
AIR BAG W/L
BELT IND
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CUTOFF TELLTALE
ECZS 1-
FUSE 13
FUSE 31
FUSE 32
FUSE BLOCK (J/B)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HYBRID EXCEPT HYBRID
IGN
LH B-PILLAR SAT SENS (-)
LH C-PILLAR SAT SENS (-)
LH DOOR SAT SENS-
LH SEAT BELT BUCKLE SW (+)
LT GRN WIRE
ODS INPUT
PNK WIRE
PPL
RED WIRE
RH B-PILLAR SAT SENS (-)
RH C-PILLAR SAT SENS (+)
RH DOOR SAT SENS (-)
RH SEAT BELT BUCKLE SW (+)
RIGHT END OF DASH)
RIGHT FRONT SIDE AIR BAG MODULE
RIGHT FRONT SIDE AIR BAG SATELLITE SENSOR
RIGHT REAR SIDE AIR BAG SATELLITE SENSOR
RIGHT SIDE CURTAIN AIR BAG MODULE
S-LH (-)
S-RH (-)
SEAT BELT REMINDER
SHIELD
SQUIB 1 RH+
SQUIB 2 RH-
SQUIB-1 LH+
SQUIB-2 LH-
TAN WIRE
UNIFIED METER CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> RIGHT SIDE CURTAIN AIR BAG MODULE
