Infiniti QX60 I facelift (2016-2021) r camera shield Wiring diagrams

This page contains all the electrical diagrams for the component. r camera shield, in which he is found in the car Infiniti QX60 I facelift (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram r camera shield (1 of 9)

Wiring diagram r camera shield for Infiniti QX60 I facelift (2016-2021) (1 of 9)

Get access

ACC RELAY OUT ACCESSORY RELAY 2 AROUND VIEW MONITOR CONTROL UNIT BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE CAN L CAN-H CAN-L SHIELD CAN GND COMPUTER DATA LINES SYSTEM DISPLAY CONTROL UNIT EXCEPT HYBRID EXCEPT HYBRID HYBRID FRONT CAMERA (CENTER OF FRONT GRILLE) FUSE 15 FUSE 29 FUSE 65 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX 1 FUSE, FUSIBLE LINK, RELAY BOX 2 FV POWER FV POWER GND FV PWR FV SERIAL FV SERIAL SIGNAL FV VIDEO + SHIELD FV VIDEO - FV VIDEO+ GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY-2 ENERGIZED IGN LEFT DOOR MIRROR LT GRN WIRE MIRROR SIGNAL 1 (PINS: 33 TO 40 NOT USED) MIRROR SIGNAL 2 PNK WIRE R CAMERA COMP R CAMERA SHIELD RED WIRE REV RIGHT DOOR MIRROR RIGHT END OF DASH) RV POWER RV POWER GND RV PWR RV PWR GND RV SERIAL SIG RV SERIAL SIGNAL RV VIDEO + SHIELD RV VIDEO - RV VIDEO+ SHIELD SHIELD M CAN GND SIDE CAMERA SIG SOUND SYSTEMS VIDEO OUTPUT + SHIELD VIDEO OUTPUT - WHT WIRE YEL WIRE

Go to component -> Around vision camera circuit -> R CAMERA SHIELD

Wiring diagram r camera shield (2 of 9)

Wiring diagram r camera shield for Infiniti QX60 I facelift (2016-2021) (2 of 9)

Get access

AUDIO HU IN+ AUDIO HU IN/OUT BLK WIRE BLU WIRE CAMERA GND CAMERA V + CAN L CAN-H COMP SHIELD COMPUTER DATA LINES SYSTEM DISPLAY CONTROL UNIT FS CONT FUSE 29 FUSE BLOCK (J/B) GRN WIRE GRY WIRE GUIDE IN - GUIDE OUT+ GUIDE SHIELD HOT W/ IGNITION RELAY-2 ENERGIZED IGN ILL INSTRUMENT CLUSTER SYSTEM LH PRE- LH SHIELD LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MIC GND MIC IN (+) SIG MIC OUT GND MIC OUT SHIELD MIC OUT SIG MIC SIG MIC VCC MICROPHONE (IN ROOF CONSOLE) NAVIGATION SYSTEM (AROUND VISION CAMERA CIRCUIT) NAVIGATION SYSTEM (REAR CAMERA CIRCUIT) NAVIGATION SYSTEM (TELEMATICS CIRCUIT) NS ON/OFF PARKING BRAKE SWITCH PKB SIG PNK WIRE PPL R CAMERA COMP R CAMERA SHIELD RED WIRE REVERSE SIG RH PRE- RH SHIELD RIGHT END OF DASH) SHIELD SPEED TAN WIRE TEL OUT TEL SHIELD VBUS W/O TELEMATICS W/ TELEMATICS WHT WIRE

Go to component -> Navigation circuit, except hybrid w/ center point audio (7 of 7) -> R CAMERA SHIELD

Wiring diagram r camera shield (3 of 9)

Wiring diagram r camera shield for Infiniti QX60 I facelift (2016-2021) (3 of 9)

Get access

AUDIO HU IN+ AUDIO HU IN/OUT BLK WIRE BLU WIRE CAMERA GND CAMERA V + CAN L CAN-H COMP SHIELD COMPUTER DATA LINES SYSTEM DISPLAY CONTROL UNIT FS CONT FUSE 29 FUSE BLOCK (J/B) GRN WIRE GRY WIRE GUIDE IN - GUIDE OUT+ GUIDE SHIELD HOT W/ IGNITION RELAY-2 ENERGIZED IGN ILL INSTRUMENT CLUSTER SYSTEM LH PRE- LH SHIELD LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MIC GND MIC IN (+) SIG MIC OUT GND MIC OUT SHIELD MIC OUT SIG MIC SIG MIC VCC MICROPHONE (IN ROOF CONSOLE) NAVIGATION SYSTEM (AROUND VISION CAMERA CIRCUIT) NAVIGATION SYSTEM (REAR CAMERA CIRCUIT) NAVIGATION SYSTEM (TELEMATICS CIRCUIT) NS ON/OFF PARKING BRAKE SWITCH PKB SIG PNK WIRE PPL R CAMERA COMP R CAMERA SHIELD RED WIRE REVERSE SIG RH PRE- RH SHIELD RIGHT END OF DASH) SHIELD SPEED TAN WIRE TEL OUT TEL SHIELD VBUS W/O TELEMATICS W/ TELEMATICS WHT WIRE

Go to component -> Navigation circuit, except hybrid w/o center point audio (6 of 6) -> R CAMERA SHIELD

Wiring diagram r camera shield (4 of 9)

Wiring diagram r camera shield for Infiniti QX60 I facelift (2016-2021) (4 of 9)

Get access

AUDIO HU IN+ AUDIO HU IN/OUT BLK WIRE BLU WIRE CAN L CAN-H COMP SHIELD COMPUTER DATA LINES SYSTEM DISPLAY CONTROL UNIT FS CONT FUSE 29 FUSE BLOCK (J/B) GRN WIRE GRY WIRE GUIDE IN - GUIDE OUT+ GUIDE SHIELD HOT W/ IGNITION RELAY-2 ENERGIZED IGN ILL INSTRUMENT CLUSTER SYSTEM LH PRE- LH SHIELD LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MIC GND MIC IN (+) SIG MIC OUT GND MIC OUT SHIELD MIC OUT SIG MIC SIG MIC VCC MICROPHONE (IN ROOF CONSOLE) NAVIGATION SYSTEM (AROUND VISION CAMERA CIRCUIT) NAVIGATION SYSTEM (TELEMATICS CIRCUIT) NS ON/OFF PARKING BRAKE SWITCH PKB SIG PNK WIRE PPL R CAMERA COMP R CAMERA SHIELD RED WIRE REVERSE SIG RH PRE- RH SHIELD RIGHT END OF DASH) SHIELD SPEED TAN WIRE TEL OUT TEL SHIELD VBUS W/O TELEMATICS W/ TELEMATICS WHT WIRE

Go to component -> Navigation circuit, hybrid (7 of 7) -> R CAMERA SHIELD

Wiring diagram r camera shield (5 of 9)

Wiring diagram r camera shield for Infiniti QX60 I facelift (2016-2021) (5 of 9)

Get access

AUX AUDIO AUX VIDEO - BLK WIRE BLU WIRE CAMERA GND CAMERA V + CAN L CAN-H COMP SHIELD COMPUTER DATA LINES SYSTEM DISPLAY CONTROL UNIT FRONT AUXILIARY INPUT JACKS FS CONT FUSE 29 FUSE BLOCK (J/B) GRN WIRE GRY WIRE GUIDE IN - GUIDE OUT+ GUIDE SHIELD HOT W/ IGNITION RELAY-2 ENERGIZED IGN ILL INSTRUMENT CLUSTER SYSTEM LH AUX AUDIO (+) LH PRE- LH SHIELD LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MIC GND MIC IN (+) SIG MIC SIG MIC VCC NAVIGATION SYSTEM NAVIGATION SYSTEM (AROUND VISION CAMERA CIRCUIT) NAVIGATION SYSTEM (REAR CAMERA CIRCUIT) NAVIGATION SYSTEM (TELEMATICS CIRCUIT) NS ON/OFF PARKING BRAKE SWITCH PKB SIG PNK WIRE PPL R CAMERA COMP R CAMERA SHIELD REAR CAMERA CIRCUIT RED WIRE REVERSE SIG RH AUX AUDIO (+) RH PRE- RH SHIELD RIGHT END OF DASH) SHIELD SHIELD SHIELD SPEED TAN WIRE TEL OUT TEL SHIELD USB D+ SIG USB GND USB VBUS SIG W/O TELEMATICS W/ TELEMATICS WHT WIRE

Go to component -> Radio circuit, except hybrid base (4 of 4) -> R CAMERA SHIELD

Wiring diagram r camera shield (6 of 9)

Wiring diagram r camera shield for Infiniti QX60 I facelift (2016-2021) (6 of 9)

Get access

AUDIO HU IN+ AUDIO HU IN/OUT BLK WIRE BLU WIRE CAMERA GND CAMERA V + CAN L CAN-H COMP SHIELD COMPUTER DATA LINES SYSTEM DISPLAY CONTROL UNIT FS CONT FUSE 29 FUSE BLOCK (J/B) GRN WIRE GRY WIRE GUIDE IN - GUIDE OUT+ GUIDE SHIELD HOT W/ IGNITION RELAY-2 ENERGIZED IGN ILL INSTRUMENT CLUSTER SYSTEM LH PRE- LH SHIELD LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MIC GND MIC IN (+) SIG MIC OUT GND MIC OUT SHIELD MIC OUT SIG MIC SIG MIC VCC MICROPHONE (IN ROOF CONSOLE) NAVIGATION SYSTEM (AROUND VISION CAMERA CIRCUIT) NAVIGATION SYSTEM (REAR CAMERA CIRCUIT) NAVIGATION SYSTEM (TELEMATICS CIRCUIT) NS ON/OFF PARKING BRAKE SWITCH PKB SIG PNK WIRE PPL R CAMERA COMP R CAMERA SHIELD RED WIRE REVERSE SIG RH PRE- RH SHIELD RIGHT END OF DASH) SHIELD SPEED TAN WIRE TEL OUT TEL SHIELD VBUS W/O TELEMATICS W/ TELEMATICS WHT WIRE

Go to component -> Radio circuit, except hybrid bose w/ center point audio (7 of 7) -> R CAMERA SHIELD

Wiring diagram r camera shield (7 of 9)

Wiring diagram r camera shield for Infiniti QX60 I facelift (2016-2021) (7 of 9)

Get access

AUDIO HU IN+ AUDIO HU IN/OUT BLK WIRE BLU WIRE CAMERA GND CAMERA V + CAN L CAN-H COMP SHIELD COMPUTER DATA LINES SYSTEM DISPLAY CONTROL UNIT FS CONT FUSE 29 FUSE BLOCK (J/B) GRN WIRE GRY WIRE GUIDE IN - GUIDE OUT+ GUIDE SHIELD HOT W/ IGNITION RELAY-2 ENERGIZED IGN ILL INSTRUMENT CLUSTER SYSTEM LH PRE- LH SHIELD LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MIC GND MIC IN (+) SIG MIC OUT GND MIC OUT SHIELD MIC OUT SIG MIC SIG MIC VCC MICROPHONE (IN ROOF CONSOLE) NAVIGATION SYSTEM (AROUND VISION CAMERA CIRCUIT) NAVIGATION SYSTEM (REAR CAMERA CIRCUIT) NAVIGATION SYSTEM (TELEMATICS CIRCUIT) NS ON/OFF PARKING BRAKE SWITCH PKB SIG PNK WIRE PPL R CAMERA COMP R CAMERA SHIELD RED WIRE REVERSE SIG RH PRE- RH SHIELD RIGHT END OF DASH) SHIELD SPEED TAN WIRE TEL OUT TEL SHIELD VBUS W/O TELEMATICS W/ TELEMATICS WHT WIRE

Go to component -> Radio circuit, except hybrid bose w/o center point audio (6 of 6) -> R CAMERA SHIELD

Wiring diagram r camera shield (8 of 9)

Wiring diagram r camera shield for Infiniti QX60 I facelift (2016-2021) (8 of 9)

Get access

AUDIO HU IN+ AUDIO HU IN/OUT BLK WIRE BLU WIRE CAN L CAN-H COMP SHIELD COMPUTER DATA LINES SYSTEM DISPLAY CONTROL UNIT FS CONT FUSE 29 FUSE BLOCK (J/B) GRN WIRE GRY WIRE GUIDE IN - GUIDE OUT+ GUIDE SHIELD HOT W/ IGNITION RELAY-2 ENERGIZED IGN ILL INSTRUMENT CLUSTER SYSTEM LH PRE- LH SHIELD LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MIC GND MIC IN (+) SIG MIC OUT GND MIC OUT SHIELD MIC OUT SIG MIC SIG MIC VCC MICROPHONE (IN ROOF CONSOLE) NAVIGATION SYSTEM (AROUND VISION CAMERA CIRCUIT) NAVIGATION SYSTEM (TELEMATICS CIRCUIT) NS ON/OFF PARKING BRAKE SWITCH PKB SIG PNK WIRE PPL R CAMERA COMP R CAMERA SHIELD RED WIRE REVERSE SIG RH PRE- RH SHIELD RIGHT END OF DASH) SHIELD SPEED TAN WIRE TEL OUT TEL SHIELD VBUS W/O TELEMATICS W/ TELEMATICS WHT WIRE

Go to component -> Radio circuit, hybrid (7 of 7) -> R CAMERA SHIELD

Wiring diagram r camera shield (9 of 9)

Wiring diagram r camera shield for Infiniti QX60 I facelift (2016-2021) (9 of 9)

Get access

BLK WIRE BLU WIRE CAMERA GND CAMERA V + CAN L CAN-H COMPUTER DATA LINES SYSTEM DISPLAY CONTROL UNIT FUSE 15 FUSE 29 FUSE BLOCK (J/B) HOT AT ALL TIMES HOT W/ IGNITION RELAY-2 ENERGIZED IGN LT GRN WIRE PNK WIRE R CAMERA COMP R CAMERA SHIELD REAR VIEW CAMERA (LEFT SIDE OF BACK DOOR) RED WIRE RIGHT END OF DASH) SHIELD WHT WIRE YEL WIRE

Go to component -> Rear view camera circuit -> R CAMERA SHIELD
