Infiniti QX60 I facelift (2016-2021) open close Wiring diagram
This page shows the only wiring diagram for the component.open close, which is found in the car Infiniti QX60 I facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram open close (1 of 1)
ACCESSORY RELAY 2
BLK WIRE
BLU WIRE
BRN WIRE
CHANGE OVER SWITCH
DEFOGGER SYSTEM
FOLD-BACK MIRRORS CIRCUIT
FUSE 65
FUSE, FUSIBLE LINK, RELAY BOX 2
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT DOOR MIRROR
LEFT RIGHT
LT BLU WIRE
LT GRN WIRE
MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH (POWER MIRROR REMOTE CONTROL SWITCH)
MIRROR SWITCH
OPEN CLOSE
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
RIGHT DOOR MIRROR
TAN WIRE
UP DOWN
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> OPEN CLOSE
