Infiniti QX60 I facelift (2016-2021) mirror sw up Wiring diagram
This page shows the only wiring diagram for the component.mirror sw up, which is found in the car Infiniti QX60 I facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror sw up (1 of 1)
AUTOMATIC DRIVE POSITIONER CONTROL UNIT
BAT (PTC)
BLK WIRE
BLU WIRE
BRN WIRE
CHANGE OVER SWITCH
DEC
DEFOGGER SYSTEM
DOWN UP
FUSE 1
FUSE BLOCK (J/B)
GND PWR
GND SENS GND
GRN WIRE
HOT AT ALL TIMES
LEFT DOOR MIRROR
LEFT RIGHT
LH MIRROR SELECT SW
LT BLU WIRE
LT GRN WIRE
MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH (POWER MIRROR REMOTE CONTROL SWITCH)
MEMORY POWER TILT, POWER TELESCOPIC CIRCUIT
MIRROR MTR (LH COMM (DWN, RH))
MIRROR MTR (LH HRZ (LH))
MIRROR MTR (LH VERT (UP))
MIRROR MTR (RH COMM (DWN, RH))
MIRROR MTR (RH HRZ (LH))
MIRROR MTR (RH VERT (UP))
MIRROR SENS (LH HRZ)
MIRROR SENS (LH VERT)
MIRROR SENS (RH HRZ)
MIRROR SENS (RH VERT)
MIRROR SW (DOWN)
MIRROR SW (LEFT)
MIRROR SW (RIGHT)
MIRROR SW UP
MIRROR SWITCH
MIRRORS SYSTEM
MIRRORS, NAVIGATION SYSTEMS
NAVIGATION SYSTEM
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
RH MIRROR SELECT SW
RIGHT DOOR MIRROR
RIGHT LEFT
SHIELD
SIDE CAMERA
STRG MTR COMM (UP/FWD)
TAN WIRE
TELESCOPIC MTR (BACK)
TELESCOPIC SW (BACK)
TELESCOPIC SW (FRONT)
TILT MTR DOWN
TILT SW (DOWN)
TILT SW (UP)
UART (TX/RX)
W/ DRIVER ASSISTANCE SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Memory seat & mirrors circuit (1 of 3) -> MIRROR SW UP
