Infiniti QX60 I facelift (2016-2021) low coolant temp ind Wiring diagram
This page shows the only wiring diagram for the component.low coolant temp ind, which is found in the car Infiniti QX60 I facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low coolant temp ind (1 of 1)
ABS IND.
ACCESSORY RELAY 1
AIR BAG IND
BCI OFF SWITCH
BELT IND
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE IND
BRN WIRE
BUZZER
CHARGE IND
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DISPLAY CONTROL UNIT
DOWN
ENGINE CONTROLS SYSTEM
EPS IND
EV IND
EXCEPT HYBRID
FEB OFF IND
FOG LIGHT IND
FUEL GAUGE
FUEL LEVEL SENSOR UNIT, FUEL PUMP (FUEL LEVEL SENSOR)
FUSE 13
FUSE 31
FUSE 65
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK BOX 1
FUSE, FUSIBLE LINK, RELAY BOX 1
FUSE, FUSIBLE LINK, RELAY BOX 2
FUSIBLE LINK O
GRN WIRE
HEV BRAKE IND (YELLOW)
HIGH BEAM ASSIST (GREEN) IND
HIGH BEAM IND (BLUE)
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
HYBRID SYSTEM WARNING LAMP IND
ILLUMINATION CONTROL SWITCH
LEFT TURN IND
LIGHT (GREEN) IND
LOW COOLANT TEMP IND
LT GRN WIRE
MALFUNCTION IND LAMP (MIL)
MASTER (YELLOW) IND
METER CONTROL SWITCH
METER ILLUMINATION
NAVIGATION SYSTEM
PARKING BRAKE SWITCH
PKB SIG
PNK WIRE
POWER TOPS SYSTEM
PPL
READY IND
RED WIRE
RIGHT TURN IND
SECURITY IND
SLIP IND
SOUND, NAVIGATION SYSTEMS
SPEEDOMETER
STARTING/CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHOMETER
TAIL (GREEN) IND
TAN WIRE
TIRE PRESSURE IND
TRANSMISSIONS SYSTEM
TRIP RESET SWITCH
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
VDC OFF IND
VSP OFF IND (HYBRID)
VSP OFF SWITCH
W/ INTELLIGENT CRUISE CONTROL HYBRID EXCEPT HYBRID
WARNING, SUPPLEMENTAL RESTRAINTS SYSTEMS
WATER TEMP GAUGE
WHT WIRE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> LOW COOLANT TEMP IND
