Infiniti QX60 I facelift (2016-2021) lh shield Wiring diagrams

This page contains all the electrical diagrams for the component. lh shield, in which he is found in the car Infiniti QX60 I facelift (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

lh shield wiring diagram (1 of 7)

Infiniti QX60 I facelift (2016-2021) lh shield wiring diagram (1 of 7)

AUDIO HU IN+ AUDIO HU IN/OUT BLK WIRE BLU WIRE CAMERA GND CAMERA V + CAN L CAN-H COMP SHIELD COMPUTER DATA LINES SYSTEM DISPLAY CONTROL UNIT FS CONT FUSE 29 FUSE BLOCK (J/B) GRN WIRE GRY WIRE GUIDE IN - GUIDE OUT+ GUIDE SHIELD HOT W/ IGNITION RELAY-2 ENERGIZED IGN ILL INSTRUMENT CLUSTER SYSTEM LH PRE- LH SHIELD LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MIC GND MIC IN (+) SIG MIC OUT GND MIC OUT SHIELD MIC OUT SIG MIC SIG MIC VCC MICROPHONE (IN ROOF CONSOLE) NAVIGATION SYSTEM (AROUND VISION CAMERA CIRCUIT) NAVIGATION SYSTEM (REAR CAMERA CIRCUIT) NAVIGATION SYSTEM (TELEMATICS CIRCUIT) NS ON/OFF PARKING BRAKE SWITCH PKB SIG PNK WIRE PPL R CAMERA COMP R CAMERA SHIELD RED WIRE REVERSE SIG RH PRE- RH SHIELD RIGHT END OF DASH) SHIELD SPEED TAN WIRE TEL OUT TEL SHIELD VBUS W/O TELEMATICS W/ TELEMATICS WHT WIRE

Go to component -> Navigation circuit, except hybrid w/ center point audio (7 of 7) -> LH SHIELD

lh shield wiring diagram (2 of 7)

Infiniti QX60 I facelift (2016-2021) lh shield wiring diagram (2 of 7)

AUDIO HU IN+ AUDIO HU IN/OUT BLK WIRE BLU WIRE CAMERA GND CAMERA V + CAN L CAN-H COMP SHIELD COMPUTER DATA LINES SYSTEM DISPLAY CONTROL UNIT FS CONT FUSE 29 FUSE BLOCK (J/B) GRN WIRE GRY WIRE GUIDE IN - GUIDE OUT+ GUIDE SHIELD HOT W/ IGNITION RELAY-2 ENERGIZED IGN ILL INSTRUMENT CLUSTER SYSTEM LH PRE- LH SHIELD LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MIC GND MIC IN (+) SIG MIC OUT GND MIC OUT SHIELD MIC OUT SIG MIC SIG MIC VCC MICROPHONE (IN ROOF CONSOLE) NAVIGATION SYSTEM (AROUND VISION CAMERA CIRCUIT) NAVIGATION SYSTEM (REAR CAMERA CIRCUIT) NAVIGATION SYSTEM (TELEMATICS CIRCUIT) NS ON/OFF PARKING BRAKE SWITCH PKB SIG PNK WIRE PPL R CAMERA COMP R CAMERA SHIELD RED WIRE REVERSE SIG RH PRE- RH SHIELD RIGHT END OF DASH) SHIELD SPEED TAN WIRE TEL OUT TEL SHIELD VBUS W/O TELEMATICS W/ TELEMATICS WHT WIRE

Go to component -> Navigation circuit, except hybrid w/o center point audio (6 of 6) -> LH SHIELD

lh shield wiring diagram (3 of 7)

Infiniti QX60 I facelift (2016-2021) lh shield wiring diagram (3 of 7)

AUDIO HU IN+ AUDIO HU IN/OUT BLK WIRE BLU WIRE CAN L CAN-H COMP SHIELD COMPUTER DATA LINES SYSTEM DISPLAY CONTROL UNIT FS CONT FUSE 29 FUSE BLOCK (J/B) GRN WIRE GRY WIRE GUIDE IN - GUIDE OUT+ GUIDE SHIELD HOT W/ IGNITION RELAY-2 ENERGIZED IGN ILL INSTRUMENT CLUSTER SYSTEM LH PRE- LH SHIELD LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MIC GND MIC IN (+) SIG MIC OUT GND MIC OUT SHIELD MIC OUT SIG MIC SIG MIC VCC MICROPHONE (IN ROOF CONSOLE) NAVIGATION SYSTEM (AROUND VISION CAMERA CIRCUIT) NAVIGATION SYSTEM (TELEMATICS CIRCUIT) NS ON/OFF PARKING BRAKE SWITCH PKB SIG PNK WIRE PPL R CAMERA COMP R CAMERA SHIELD RED WIRE REVERSE SIG RH PRE- RH SHIELD RIGHT END OF DASH) SHIELD SPEED TAN WIRE TEL OUT TEL SHIELD VBUS W/O TELEMATICS W/ TELEMATICS WHT WIRE

Go to component -> Navigation circuit, hybrid (7 of 7) -> LH SHIELD

lh shield wiring diagram (4 of 7)

Infiniti QX60 I facelift (2016-2021) lh shield wiring diagram (4 of 7)

AUX AUDIO AUX VIDEO - BLK WIRE BLU WIRE CAMERA GND CAMERA V + CAN L CAN-H COMP SHIELD COMPUTER DATA LINES SYSTEM DISPLAY CONTROL UNIT FRONT AUXILIARY INPUT JACKS FS CONT FUSE 29 FUSE BLOCK (J/B) GRN WIRE GRY WIRE GUIDE IN - GUIDE OUT+ GUIDE SHIELD HOT W/ IGNITION RELAY-2 ENERGIZED IGN ILL INSTRUMENT CLUSTER SYSTEM LH AUX AUDIO (+) LH PRE- LH SHIELD LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MIC GND MIC IN (+) SIG MIC SIG MIC VCC NAVIGATION SYSTEM NAVIGATION SYSTEM (AROUND VISION CAMERA CIRCUIT) NAVIGATION SYSTEM (REAR CAMERA CIRCUIT) NAVIGATION SYSTEM (TELEMATICS CIRCUIT) NS ON/OFF PARKING BRAKE SWITCH PKB SIG PNK WIRE PPL R CAMERA COMP R CAMERA SHIELD REAR CAMERA CIRCUIT RED WIRE REVERSE SIG RH AUX AUDIO (+) RH PRE- RH SHIELD RIGHT END OF DASH) SHIELD SHIELD SHIELD SPEED TAN WIRE TEL OUT TEL SHIELD USB D+ SIG USB GND USB VBUS SIG W/O TELEMATICS W/ TELEMATICS WHT WIRE

Go to component -> Radio circuit, except hybrid base (4 of 4) -> LH SHIELD

lh shield wiring diagram (5 of 7)

Infiniti QX60 I facelift (2016-2021) lh shield wiring diagram (5 of 7)

AUDIO HU IN+ AUDIO HU IN/OUT BLK WIRE BLU WIRE CAMERA GND CAMERA V + CAN L CAN-H COMP SHIELD COMPUTER DATA LINES SYSTEM DISPLAY CONTROL UNIT FS CONT FUSE 29 FUSE BLOCK (J/B) GRN WIRE GRY WIRE GUIDE IN - GUIDE OUT+ GUIDE SHIELD HOT W/ IGNITION RELAY-2 ENERGIZED IGN ILL INSTRUMENT CLUSTER SYSTEM LH PRE- LH SHIELD LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MIC GND MIC IN (+) SIG MIC OUT GND MIC OUT SHIELD MIC OUT SIG MIC SIG MIC VCC MICROPHONE (IN ROOF CONSOLE) NAVIGATION SYSTEM (AROUND VISION CAMERA CIRCUIT) NAVIGATION SYSTEM (REAR CAMERA CIRCUIT) NAVIGATION SYSTEM (TELEMATICS CIRCUIT) NS ON/OFF PARKING BRAKE SWITCH PKB SIG PNK WIRE PPL R CAMERA COMP R CAMERA SHIELD RED WIRE REVERSE SIG RH PRE- RH SHIELD RIGHT END OF DASH) SHIELD SPEED TAN WIRE TEL OUT TEL SHIELD VBUS W/O TELEMATICS W/ TELEMATICS WHT WIRE

Go to component -> Radio circuit, except hybrid bose w/ center point audio (7 of 7) -> LH SHIELD

lh shield wiring diagram (6 of 7)

Infiniti QX60 I facelift (2016-2021) lh shield wiring diagram (6 of 7)

AUDIO HU IN+ AUDIO HU IN/OUT BLK WIRE BLU WIRE CAMERA GND CAMERA V + CAN L CAN-H COMP SHIELD COMPUTER DATA LINES SYSTEM DISPLAY CONTROL UNIT FS CONT FUSE 29 FUSE BLOCK (J/B) GRN WIRE GRY WIRE GUIDE IN - GUIDE OUT+ GUIDE SHIELD HOT W/ IGNITION RELAY-2 ENERGIZED IGN ILL INSTRUMENT CLUSTER SYSTEM LH PRE- LH SHIELD LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MIC GND MIC IN (+) SIG MIC OUT GND MIC OUT SHIELD MIC OUT SIG MIC SIG MIC VCC MICROPHONE (IN ROOF CONSOLE) NAVIGATION SYSTEM (AROUND VISION CAMERA CIRCUIT) NAVIGATION SYSTEM (REAR CAMERA CIRCUIT) NAVIGATION SYSTEM (TELEMATICS CIRCUIT) NS ON/OFF PARKING BRAKE SWITCH PKB SIG PNK WIRE PPL R CAMERA COMP R CAMERA SHIELD RED WIRE REVERSE SIG RH PRE- RH SHIELD RIGHT END OF DASH) SHIELD SPEED TAN WIRE TEL OUT TEL SHIELD VBUS W/O TELEMATICS W/ TELEMATICS WHT WIRE

Go to component -> Radio circuit, except hybrid bose w/o center point audio (6 of 6) -> LH SHIELD

lh shield wiring diagram (7 of 7)

Infiniti QX60 I facelift (2016-2021) lh shield wiring diagram (7 of 7)

AUDIO HU IN+ AUDIO HU IN/OUT BLK WIRE BLU WIRE CAN L CAN-H COMP SHIELD COMPUTER DATA LINES SYSTEM DISPLAY CONTROL UNIT FS CONT FUSE 29 FUSE BLOCK (J/B) GRN WIRE GRY WIRE GUIDE IN - GUIDE OUT+ GUIDE SHIELD HOT W/ IGNITION RELAY-2 ENERGIZED IGN ILL INSTRUMENT CLUSTER SYSTEM LH PRE- LH SHIELD LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MIC GND MIC IN (+) SIG MIC OUT GND MIC OUT SHIELD MIC OUT SIG MIC SIG MIC VCC MICROPHONE (IN ROOF CONSOLE) NAVIGATION SYSTEM (AROUND VISION CAMERA CIRCUIT) NAVIGATION SYSTEM (TELEMATICS CIRCUIT) NS ON/OFF PARKING BRAKE SWITCH PKB SIG PNK WIRE PPL R CAMERA COMP R CAMERA SHIELD RED WIRE REVERSE SIG RH PRE- RH SHIELD RIGHT END OF DASH) SHIELD SPEED TAN WIRE TEL OUT TEL SHIELD VBUS W/O TELEMATICS W/ TELEMATICS WHT WIRE

Go to component -> Radio circuit, hybrid (7 of 7) -> LH SHIELD
