Infiniti QX60 I facelift (2016-2021) left vanity lamp Wiring diagram
This page shows the only wiring diagram for the component.left vanity lamp, which is found in the car Infiniti QX60 I facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left vanity lamp (1 of 1)
BETWEEN FULL STROKE FULL STROKE, LOCK SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CARGO LAMP
DOOR
DOOR ON
EXCEPT HYBRID
FRONT ROOM/MAP LAMP ASSEMBLY
GRN WIRE
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR SWITCH (ALL)
INTERIOR SWITCH (DOOR)
KEY CYLINDER SWITCH
LEFT FRONT DOOR LOCK ASSEMBLY
LEFT MAP LAMP SWITCH
LEFT PERSONAL LAMP
LEFT VANITY LAMP
LT BLU WIRE
LT GRN WIRE
MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH
OFF
ON OFF
RED WIRE
RIGHT END OF DASH)
RIGHT MAP LAMP SWITCH
RIGHT PERSONAL LAMP
RIGHT POWER WINDOW, DOOR LOCK/UNLOCK SWITCH
RIGHT VANITY LAMP
UNLOCK BETWEEN SWITCH FULL FULL STROKE STROKE,
UNLOCK LOCK
W/ MEMORY
W/O MEMORY
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> LEFT VANITY LAMP
