Infiniti QX60 I facelift (2016-2021) lane camera unit Wiring diagrams
This page contains all the electrical diagrams for the component. lane camera unit, in which he is found in the car Infiniti QX60 I facelift (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram lane camera unit (1 of 3)
ACCELERATOR PEDAL ACTUATOR
ADAS CONTROL UNIT (RIGHT REAR OF STORAGE BOX)
AUTOMATIC BACK DOOR CONTROL MODULE
AWD CONTROL UNIT (IF EQUIPPED) (LEFT REAR OF STORAGE BOX)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
DRIVER ASSISTANCE BUZZER CONTROL MODULE
DRIVER SEAT CONTROL UNIT
DRIVER SIDE PRE-CRASH SEAT BELT CONTROL UNIT
GRY WIRE
IC CAN H
IC CAN L
ICC SENSOR
ITS CAN-H
ITS CAN-L
LANE CAMERA UNIT
LEFT SIDE RADAR
PNK WIRE
RIGHT SIDE RADAR
SHIELD
SONAR CONTROL UNIT
TAN WIRE
V CAN-H
V CAN-L
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit, except hybrid w/ can gateway & icc (3 of 3) -> LANE CAMERA UNIT
Wiring diagram lane camera unit (2 of 3)
ACCELERATOR PEDAL ACTUATOR/ ACCELERATOR PEDAL POSITION SENSOR
ADAS CONTROL UNIT (RIGHT REAR OF STORAGE BOX)
AUTOMATIC BACK DOOR CONTROL MODULE
AWD CONTROL UNIT (IF EQUIPPED) (LEFT REAR OF STORAGE BOX)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CAN-L SHIELD CAN SHIELD
DRIVER ASSISTANCE BUZZER CONTROL MODULE
DRIVER SEAT CONTROL UNIT
DRIVER SIDE PRE-CRASH SEAT BELT CONTROL UNIT
GRY WIRE
ICC SENSOR (BEHIND RIGHT SIDE OF FRONT BUMPER)
ITS CAN-H
ITS CAN-L
LANE CAMERA UNIT
LEFT SIDE RADAR
PNK CAN-H WIRE
RED WIRE
RIGHT SIDE RADAR
SHIELD
SONAR CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit, hybrid w/ icc (4 of 4) -> LANE CAMERA UNIT
Wiring diagram lane camera unit (3 of 3)
ADAS CONTROL UNIT (RIGHT REAR OF STORAGE BOX)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
DRIVER ASSISTANCE BUZZER CONTROL MODULE
EXCEPT HYBRID
EXCEPT HYBRID HYBRID
FUSE 1
FUSE 30
FUSE BLOCK (J/B)
GRN WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN
ITS ALERT SYS SW
ITS ALERT SYS SW IND
ITS CAN-H
ITS CAN-L
LANE CAMERA UNIT
LT GRN WIRE
RED WIRE
RIGHT END OF DASH)
SPEAKER
V CAN H CAN H
V-CAN-L CAN-L
WARNING BUZZER (LEFT END OF DASH)
WARNING SYSTEM SWITCH
WHT WIRE
YEL WIRE
Go to component -> Lane departure warning circuit -> LANE CAMERA UNIT
