Infiniti QX60 I facelift (2016-2021) fuse 39 Wiring diagram
This page shows the only wiring diagram for the component.fuse 39, which is found in the car Infiniti QX60 I facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 39 (1 of 1)
A/F 1 (BANK 1)
A/F 1 (BANK 2)
A/F SENS 1
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ECM RELAY
ECM RLY
ENG MOUNT CTRL VLV
FUEL PMP RLY
FUEL PUMP RELAY
FUSE 38
FUSE 39
FUSE 40
FUSE 44
FUSE 45
FUSE 46
FUSE 47
FUSE 55
FUSE 56
GRN WIRE
GRY WIRE
IGN SIG 3
IGN SIG 6
IGNITION RELAY 1
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LT BLU WIRE
LT GRN WIRE
OIL PR CTRL VLV
OXY SENS (BANK 2)
PNK WIRE
PNP SIG
PPL
RED WIRE
SENS GND
SHIELD
THROT MTR CTRL CLS
THROT MTR CTRL OPN
THROT MTR RLY
THROTTLE CONTROL MOTOR RELAY
VIAS CTRL SOL VLV 1
VIAS CTRL SOL VLV 2
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l (4 of 7) -> FUSE 39
