Infiniti QX60 I facelift (2016-2021) driver sw Wiring diagram
This page shows the only wiring diagram for the component.driver sw, which is found in the car Infiniti QX60 I facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver sw (1 of 1)
AUTOMATIC BACK DOOR CLOSE SWITCH
AUTOMATIC BACK DOOR CONTROL MODULE
AUTOMATIC BACK DOOR MAIN SWITCH
AUTOMATIC BACK DOOR SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
CAN L
CAN SHIELD
CAN-H
CIRCUIT BREAKER 1
CLOSE SW
COMPUTER DATA LINES SYSTEM
DRIVER SW
EXCEPT HYBRID
EXCEPT HYBRID HYBRID IF EQUIPPED
FUSE, FUSIBLE LINK BOX
FUSIBLE LINK N
GRY WIRE
HALF LATCH SW
HALL GND
HOT AT ALL TIMES
INSIDE CLOSE SW
KICK SENS PWR
KICK SENS SERIAL SIG
LATCH MTR CLOSE
LATCH MTR OPEN
LEFT SPINDLE UNIT
LH A SIGN
LH B SIGN
LH MTR CLOSE
LH MTR OPEN
LH POWER
LH TOUCH SENS
LOGIC
LT BLU WIRE
LT GRN WIRE
MAIN SW
NOISE SHIELD LATCH
OPEN SW
PNK WIRE
PPL
RED WIRE
RH A SIGN
RH B SIGN
RH MTR CLOSE
RH MTR OPEN
RH POWER
RH TOUCH SENS
RIGHT END OF DASH)
RIGHT SPINDLE UNIT
SHIELD
SPINDLE MOTOR
TAN WIRE
TOUCH SENS GND
WHT WIRE
YEL WIRE
Go to component -> Automatic back door circuit (1 of 2) -> DRIVER SW
