Infiniti QX60 I facelift (2016-2021) driver air bag module Wiring diagram
This page shows the only wiring diagram for the component.driver air bag module, which is found in the car Infiniti QX60 I facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver air bag module (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION SWITCH (SPIRAL CABLE)
CRASH ZONE SENSOR
DRIVER AIR BAG MODULE
DRIVER SIDE SEAT BELT BUCKLE SWITCH
FRONT PASSENGER AIR BAG MODULE (RIGHT SIDE OF DASH)
FRONT PASSENGER AIR BAG MODULE (SERVICE REPLACEMENT)
GRN WIRE
GRY WIRE
LAP BELT
LEFT "C" PILLAR)
LEFT FRONT DOOR SATELLITE SENSOR
LEFT FRONT SEAT BELT PRE-TENSIONER
LT GRN WIRE
MULTI- FUNCTION SWITCH
PASSENGER AIR BAG OFF INDICATOR
PASSIVE RESTRAINTS SYSTEM
PPL
RED WIRE
RIGHT FRONT DOOR SATELLITE SENSOR
SHIELD
SHIELD (OR
SHOULDER BELT
STEERING COLUMN)
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> DRIVER AIR BAG MODULE
