Infiniti QX60 I facelift (2016-2021) cruise control, transmissions systems Wiring diagrams
This page contains all the electrical diagrams for the component. cruise control, transmissions systems, in which he is found in the car Infiniti QX60 I facelift (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram cruise control, transmissions systems (1 of 2)
A/C RELAY
AIR CONDITIONING, COOLING FANS SYSTEMS
ANTI-LOCK BRAKES, ELECTRONIC POWER STEERING SYSTEMS
BLK WIRE
BLU WIRE
BRN WIRE
CRUISE CONTROL, TRANSMISSIONS SYSTEMS
ECM RELAY
ENGINE CONTROLS SYSTEM
FROM FUSE, FUSIBLE LINK BOX 1 (DIAGRAM 1 OF 4)
FROM FUSIBLE LINK BOX (BATTERY) (DIAGRAM 1 OF 4)
FROM IGNITION RELAY 1 (DIAGRAM 4 OF 4)
FRONT FOG LAMP RELAY
FRONT WIPER HIGH RELAY
FRONT WIPER RELAY
FUEL PUMP RELAY
FUSE 26
FUSE 41
FUSE 42
FUSE 43
FUSE 44
FUSE 45
FUSE 46
FUSE 47
FUSE 48
FUSE 49
FUSE 50
FUSE 51
FUSE 52
FUSE 53
FUSE 55
FUSE 56
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HEADLAMP HIGH RELAY
HEADLAMP LOW RELAY
HEADLIGHTS SYSTEM
IGNITION RELAY 1
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LT BLU WIRE
LT GRN WIRE
PPL
RED WIRE
STARTER RELAY
TAIL LAMP RELAY
THROTTLE CONTROL MOTOR RELAY
TO FUSE 47 (DIAGRAM 4 OF 4)
TRANSMISSIONS SYSTEM
TRANSMISSIONS, EXTERIOR LIGHTS SYSTEMS
TRANSMISSIONS, STARTING/ CHARGING SYSTEMS
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (4 of 4) -> CRUISE CONTROL, TRANSMISSIONS SYSTEMS
Wiring diagram cruise control, transmissions systems (2 of 2)
A/C RELAY
AIR CONDITIONING SYSTEM
AIR CONDITIONING, COOLING FANS, TRANSMISSIONS SYSTEMS
ANTI-LOCK BRAKES, ELECTRONIC POWER STEERING SYSTEMS
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
CRUISE CONTROL, TRANSMISSIONS SYSTEMS
ECM RELAY
ELECTRONIC POWER STEERING SYSTEM
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS, STARTING/CHARGING, TRANSMISSIONS SYSTEMS
EXTERIOR LIGHTS, TRANSMISSIONS SYSTEMS
FROM FUSE, FUSIBLE LINK, RELAY BOX 1 (DIAGRAM 1 OF 4)
FROM FUSIBLE LINK BOX (BATTERY) (DIAGRAM 1 OF 4)
FROM IGNITION RELAY 1 (DIAGRAM 4 OF 4)
FRONT FOG LAMP RELAY
FRONT WIPER HIGH RELAY
FRONT WIPER RELAY
FUEL PUMP RELAY
FUSE 41
FUSE 42
FUSE 43
FUSE 44
FUSE 45
FUSE 46
FUSE 47
FUSE 48
FUSE 49
FUSE 50
FUSE 51
FUSE 52
FUSE 53
FUSE 55
FUSE 56
FUSE 71
FUSE 72
FUSE 73
FUSE 74
FUSE 75
FUSE 81
FUSIBLE LINK Q
FUSIBLE LINK R
FUSIBLE LINK T
FUSIBLE LINK V
GRN WIRE
HEADLAMP HIGH RELAY
HEADLAMP LOW RELAY
HEADLIGHTS SYSTEM
HIGH VOLTAGE FUSE, FUSIBLE LINK, RELAY BOX
IGNITION RELAY 1
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PNK WIRE
PPL
RED WIRE
SEATS SYSTEM
SELF SHUT OFF RELAY
STARTER RELAY
TAIL LAMP RELAY
TAN WIRE
THROTTLE CONTROL MOTOR RELAY
TO FUSE 47 (DIAGRAM 4 OF 4)
TO FUSE BLOCK (J/B) (DIAGRAM 2 OF 4)
TO FUSE BLOCK (J/B) (DIAGRAM 3 OF 4)
TO FUSE, FUSIBLE LINK, RELAY BOX 2 (DIAGRAM 1 OF 4)
TRANSMISSIONS SYSTEM
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit, hybrid (4 of 4) -> CRUISE CONTROL, TRANSMISSIONS SYSTEMS
