Infiniti QX60 I facelift (2016-2021) coast/ set switch cancel switch Wiring diagram
This page shows the only wiring diagram for the component.coast/ set switch cancel switch, which is found in the car Infiniti QX60 I facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram coast/ set switch cancel switch (1 of 1)
ACCELERATE/ RESUME SWITCH
ASCD STEERING SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COAST/ SET SWITCH CANCEL SWITCH
COMBINATION METER
COMBINATION SWITCH (SPIRAL CABLE)
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
DISPLAY
FUSE 31
FUSE BLOCK (J/B)
GRN WIRE
HOT IN ON OR START
INPUT SPD SENS
INPUT SPEED SENSOR (LEFT SIDE OF TRANSMISSION)
LT GRN WIRE
MAIN (ON/ OFF) SWITCH
OUTPUT SPD SENS
OUTPUT SPEED SENSOR (ON TRANSAXLE)
PNK WIRE
PRI SPD SENS
PRIMARY SPEED SENSOR (ON TRANSAXLE)
RED WIRE
SENSOR 1
SENSOR 2
SHIELD
STEERING COLUMN)
TAN WIRE
TCM (TRANSMISSION CONTROL MODULE)
THROTTLE CONTROL MOTOR
THROTTLE POSITION SENSOR
UNIFIED METER
VIGN
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit, except hybrid (2 of 2) -> COAST/ SET SWITCH CANCEL SWITCH
