Infiniti QX60 I facelift (2016-2021) climate controlled seat control unit Wiring diagram
This page shows the only wiring diagram for the component.climate controlled seat control unit, which is found in the car Infiniti QX60 I facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram climate controlled seat control unit (1 of 1)
ABS ACTUATOR, ELECTRIC UNIT
BLK WIRE
CAN GATEWAY, DONGLE UNIT,
CLIMATE CONTROLLED SEAT CONTROL UNIT
CONTROL UNIT)
COOLING FAN CONTROL MODULE, RIGHT FRONT COMBINATION LAMP
DRIVER ASSISTANCE BUZZER CONTROL MODULE, LEFT FRONT INNER SONAR SENSOR SHIELD
IONIZER (W/ CLIMATE CONTROLLED SEAT RELAY),
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LEFT FRONT COMBINATION LAMP, RIGHT FRONT COMBINATION LAMP
MULTI- FUNCTION SWITCH
POWER STEERING CONTROL MODULE
RIGHT END OF DASH)
Go to component -> Ground distribution circuit, hybrid (1 of 2) -> CLIMATE CONTROLLED SEAT CONTROL UNIT
