Infiniti QX60 I facelift (2016-2021) buckle sw rh no Wiring diagram
This page shows the only wiring diagram for the component.buckle sw rh no, which is found in the car Infiniti QX60 I facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram buckle sw rh no (1 of 1)
BLK WIRE
BLU WIRE
BRAKE PEDAL STROKE SENSOR
BUCKLE SW LH NO
BUCKLE SW RH NO
CAN-H
COMPUTER DATA LINES SYSTEM
DRIVER SEAT BELT BUCKLE SWITCH
DRIVER SIDE PRE-CRASH SEAT BELT CONTROL UNIT
FUSE 14
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK BOX 1
FUSIBLE LINK L
FUSIBLE LINK M
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT "C" PILLAR)
LOCAL COMM 1
LOCAL COMM 2
LOCAL COMM 2 SHIELD SHIELD GND
MOTOR BAT
MOTOR GND
OUT 1 -
OUT 2 +
PASSENGER SEAT BELT BUCKLE SWITCH
PASSENGER SIDE PRE-CRASH SEAT BELT CONTROL UNIT
PNK CAN-L WIRE
PNK SIG BAT WIRE
PNK WIRE
RED WIRE
SENS GND 1
SENS POWER 1
SHIELD
SHIELD GND
SIG BAT
SIG GND
WHT WIRE
YEL WIRE
Go to component -> Passive restraints circuit, except hybrid -> BUCKLE SW RH NO
