Infiniti QX60 I facelift (2016-2021) brake rly Wiring diagrams
This page contains all the electrical diagrams for the component. brake rly, in which he is found in the car Infiniti QX60 I facelift (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram brake rly (1 of 3)
ABS IND.
ADAS CONTROL UNIT
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE IND
BRAKE RLY
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FUSE 10
FUSE 13
FUSE 30
FUSE 31
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
ICC BRAKE HOLD RELAY
LT GRN WIRE
PARKING BRAKE SWITCH
PNK PNK WIRE
PNK WIRE
RED WIRE
SHIELD
SLIP IND
STOP LAMP SW
STOP LAMP SWITCH
TAN WIRE
UNIFIED METER CONTROL UNIT
VACUUM SENSOR
VDC OFF IND
VDC RESISTOR
W/ INTELLIGENT CRUISE CONTROL
W/ INTELLIGENT CRUISE CONTROL W/0 INTELLIGENT CRUISE CONTROL
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit, except hybrid (2 of 2) -> BRAKE RLY
Wiring diagram brake rly (2 of 3)
ADAS CONTROL UNIT
BLK WIRE
BRAKE RLY
BRAKE STROKE SENSOR
BRN WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
FUSE 10
FUSE 30
FUSE 31
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
ICC BRAKE HOLD RELAY
LEFT REAR WHEEL SENSOR
LT BLU WIRE
PNK WIRE
RED WIRE
SHIELD
TAN WIRE
W/0 INTELLIGENT CRUISE CONTROL
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit, hybrid (2 of 3) -> BRAKE RLY
Wiring diagram brake rly (3 of 3)
ABS/TCS/VDC CONTROL UNIT ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
ADAS CONTROL UNIT (RIGHT REAR OF STORAGE BOX)
BCI OFF SW
BLK WIRE
BLU WIRE
BRAKE RLY
BRN WIRE
CAN L
CAN-H
COMPUTER
COMPUTER DATA LINES SYSTEM
DATA LINES
FUSE 1
FUSE 10
FUSE 30
FUSE 31
FUSE 46
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HEV CAN-H
HEV CAN-L
HOT AT ALL TIMES
HOT W/ IGNITION RELAY 1 ENERGIZED
HOT W/ IGNITION RELAY-2 ENERGIZED
ICC SENSOR
IGN
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
ITS ALERT SYS SW
ITS ALERT SYS SW IND
ITS CAN-H
ITS CAN-L
LT BLU WIRE
LT GRN WIRE
OUTPUT SPD SENS
OUTPUT SPEED SENSOR (ON TRANSAXLE)
PNK IGN WIRE
PNK WIRE
PRI SPD SENS
PRIMARY SPEED SENSOR (ON TRANSAXLE)
RED WIRE
STOP LAMP SW
SYSTEM
TAN WIRE
TCM (TRANSMISSION CONTROL MODULE)
VIGN
WHT WIRE
YEL WIRE
Go to component -> Intelligent cruise control circuit, hybrid (1 of 2) -> BRAKE RLY
