Infiniti QX60 I facelift (2016-2021) automatic back door close switch Wiring diagrams

AUTOMATIC BACK DOOR CLOSE SWITCH AUTOMATIC BACK DOOR CONTROL MODULE AUTOMATIC BACK DOOR MAIN SWITCH AUTOMATIC BACK DOOR SWITCH BLK WIRE BLU WIRE BRN WIRE BUZZER CAN L CAN SHIELD CAN-H CIRCUIT BREAKER 1 CLOSE SW COMPUTER DATA LINES SYSTEM DRIVER SW EXCEPT HYBRID EXCEPT HYBRID HYBRID IF EQUIPPED FUSE, FUSIBLE LINK BOX FUSIBLE LINK N GRY WIRE HALF LATCH SW HALL GND HOT AT ALL TIMES INSIDE CLOSE SW KICK SENS PWR KICK SENS SERIAL SIG LATCH MTR CLOSE LATCH MTR OPEN LEFT SPINDLE UNIT LH A SIGN LH B SIGN LH MTR CLOSE LH MTR OPEN LH POWER LH TOUCH SENS LOGIC LT BLU WIRE LT GRN WIRE MAIN SW NOISE SHIELD LATCH OPEN SW PNK WIRE PPL RED WIRE RH A SIGN RH B SIGN RH MTR CLOSE RH MTR OPEN RH POWER RH TOUCH SENS RIGHT END OF DASH) RIGHT SPINDLE UNIT SHIELD SPINDLE MOTOR TAN WIRE TOUCH SENS GND WHT WIRE YEL WIRE

AS DOOR SW AUTOMATIC BACK DOOR CLOSE SWITCH BACK DOOR LOCK ASSEMBLY (DOOR AJAR SWITCH) BACK DOOR SW BAT BCM FUSE BAT POWER F/L BAT SAVER OUTPUT BCM (BODY CONTROL MODULE) (BEHIND INSTRUMENT CLUSTER) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM DIODE 2 DOOR HANDLE LAMP DR DOOR SW EXCEPT HYBRID EXCEPT HYBRID HYBRID FUSE 1 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK BOX 1 FUSE, FUSIBLE LINK, RELAY BOX 1 FUSIBLE LINK O GRN WIRE HOT AT ALL TIMES LEFT FOOT LAMP LEFT FRONT DOOR SWITCH LEFT FRONT OUTSIDE HANDLE ASSEMBLY LEFT FRONT STEP LAMP LEFT REAR DOOR SWITCH LT BLU WIRE LT GRN WIRE PNK WIRE PPL PW LIN/COM RED WIRE RIGHT FOOT LAMP RIGHT FRONT DOOR SWITCH RIGHT FRONT OUTSIDE HANDLE ASSEMBLY RIGHT FRONT STEP LAMP RIGHT REAR DOOR SWITCH RL DOOR SW ROOM LAMP CONT RR DOOR SW STEP LAMP CONT TAN WIRE WHT WIRE YEL WIRE
