Wiring diagram: Transmission 2.5l hybrid — 2.5l hybrid, awd circuit Infiniti QX60 I
All systems
- Air conditioning 2
- Anti-lock brakes
- Anti-theft 2
- Body control modules
- Computer data lines 12
- Cooling fan
- Cruise control 4
- Defoggers
- Electronic power steering 2
- Engine performance 2.5l hybrid 2
- Engine performance 3.5l
- Exterior lights 3
- Ground distribution 2
- Headlights 4
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems 2
- Navigation 8
- Passive restraints 2
- Power distribution 2
- Power door locks
- Power mirrors 6
- Power seats 8
- Power top/sunroof
- Power windows
- Radio 12
- Shift interlock
- Starting/charging 2
- Supplemental restraints
- Transmission 2.5l hybrid 2
- Transmission 3.5l 2
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer 2
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
