Supplemental restraints circuit for Infiniti QX60 I (2013-2016)

Supplemental restraints circuit (1 of 3)

QX60 Infiniti I (2013-2016): Supplemental restraints circuit (1 of 3)

Get access

1 2 IGN GND 3 4 5 6 7 8 9 18 19 20 21 22 23 24 25 51 52 53 54 59 60 DR 1+ DR 1- DR 2- DR 2+ AIR BAG DIAGNOSIS SENSOR UNIT (UNDER FRONT OF CENTER CONSOLE) AIR BAG IND BELT IND BLK WIRE BLU WIRE BRN WIRE COMBINATION METER COMPUTER DATA LINES SYSTEM FUSE 13 FUSE 31 FUSE 32 FUSE BLOCK (J/B) (LOWER LEFT END OF DASH) GRN WIRE HOT AT ALL TIMES HOT IN ON OR START J/C LT GRN WIRE NCA WIRE PNK WIRE PPL RED WIRE RIGHT END OF DASH) RIGHT FRONT SIDE AIR BAG MODULE (OUTER EDGE OF RIGHT FRONT SEAT BACK) RIGHT FRONT SIDE AIR BAG SATELLITE SENSOR (BASE OF RIGHT FRONT "B" PILLAR) RIGHT REAR SIDE AIR BAG SATELLITE SENSOR RIGHT SIDE CURTAIN AIR BAG MODULE (RIGHT SIDE OUTER REAR ROOF RAIL) SHIELD TAN WIRE UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) WHT WIRE YEL WIRE

Supplemental restraints circuit (2 of 3)

QX60 Infiniti I (2013-2016): Supplemental restraints circuit (2 of 3)

Get access

BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FRONT INNER OCCUPANT CLASSIFICATION SYSTEM SENSOR (UNDER FRONT SIDE OF FRONT GRN WIRE GRY WIRE LAP BELT LEFT "C" PILLAR) LEFT FRONT SIDE AIR BAG MODULE (OUTER EDGE OF LEFT FRONT SEAT BACK) LEFT FRONT SIDE AIR BAG SATELLITE SENSOR (BASE OF LEFT FRONT "B" PILLAR) LEFT REAR SIDE AIR BAG SATELLITE SENSOR (BEHIND LEFT REAR QUARTERPANEL) LEFT SIDE CURTAIN AIR BAG MODULE (LEFT SIDE OUTER REAR ROOF RAIL) LT BLU WIRE LT GRN WIRE NCA WIRE OCCUPANT CLASSIFICATION SYSTEM CONTROL UNIT (UNDER FRONT PASSENGER'S SEAT) PASSENGER SIDE SEAT BELT BUCKLE SWITCH (IN RIGHT FRONT SEAT BELT BUCKLE) PASSENGER'S SEAT) PASSIVE RESTRAINTS SYSTEM PPL PRE-TENSIONER (BASE OF LEFT FRONT "B" PILLAR) REAR INNER OCCUPANT CLASSIFICATION SYSTEM SENSOR (UNDER REAR SIDE OF FRONT RED WIRE RED/BLK WIRE RIGHT FRONT SEAT BELT SHIELD SHOULDER BELT TAN WIRE WHT WIRE WHT/BLU WIRE YEL WIRE

Supplemental restraints circuit (3 of 3)

QX60 Infiniti I (2013-2016): Supplemental restraints circuit (3 of 3)

Get access

A/C, AV SWITCH ASSEMBLY BLK WIRE BLU WIRE BRN WIRE COMBINATION SWITCH (SPIRAL CABLE) (STEERING COLUMN) CRASH ZONE SENSOR DRIVER AIR BAG MODULE (IN STEERING WHEEL) DRIVER SIDE SEAT BELT BUCKLE SWITCH (IN RESPECTIVE SEAT BELT BUCKLE ASSEMBLY) FRONT PASSENGER AIR BAG MODULE (RIGHT SIDE OF DASH) FRONT PASSENGER AIR BAG MODULE (SERVICE REPLACEMENT) GRN WIRE GRY WIRE LAP BELT LEFT "C" PILLAR) LEFT FRONT DOOR SATELLITE SENSOR (FRONT OF LEFT FRONT DOOR) LEFT FRONT SEAT BELT PRE-TENSIONER (BASE OF LEFT FRONT "B" PILLAR) LT GRN WIRE PASSIVE RESTRAINTS SYSTEM PPL PPL SHIELD SHIELD RED WIRE RIGHT FRONT DOOR SATELLITE SENSOR (FRONT OF RIGHT FRONT DOOR) SHIELD SHOULDER BELT TAN WIRE WHT WIRE YEL WIRE
