Infiniti QX60 I (2013-2016) turn tail stop signal Wiring diagram
This page shows the only wiring diagram for the component.turn tail stop signal, which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn tail stop signal (1 of 1)
38 39 PNK CAN-L CAN-H COMPUTER DATA LINES SYSTEM WIRE
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
COMBINATION METER
COMPUTER DATA LINES SYSTEM (LEFT REAR OF ENGINE COMPT)
CPU IGN 1 IGN 1 TAIL/L RLY RLY RLY GND CAN-H CAN-L (SIG)
ELECTRIC BRAKE (PRE-WIRING) (LEFT SIDE OF DASH)
ELECTRIC BRAKE TRAILER RECEPTACLE
EXCEPT HYBRID HYBRID
FUSE 31
FUSE 52 FUSE 51
FUSIBLE LINK BOX
FUSIBLE LINK BOX (BATTERY) (ON BATTERY POSITIVE (+) POST)
FUSIBLE LINK C
FUSIBLE LINK D
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BLOCK (J/B) (LOWER LEFT END OF DASH) FUSE 13
HOT IN ON OR START
IGN
IGNITION RELAY 1
LEFT "C" PILLAR)
LEFT REAR LEFT LICENSE PLATE LAMP COMBINATION LAMP
LEFT TURN IND
LT GRN WIRE
NCA WIRE
PNK WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT LICENSE PLATE LAMP
RIGHT REAR COMBINATION LAMP
RIGHT TURN IND
STOP
TAIL
TAIL (GREEN) IND
TAILLAMP RELAY
TAN WIRE
TRAILER)
TURN SIGNAL
TURN TAIL STOP SIGNAL
UNIFIED METER CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (3 of 3) -> TURN TAIL STOP SIGNAL
