Infiniti QX60 I (2013-2016) sens gnd app sens 1 Wiring diagram
This page shows the only wiring diagram for the component.sens gnd app sens 1, which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sens gnd app sens 1 (1 of 1)
1 34 MTR PWR SPLY MTR RLY
ACCELERATOR PEDAL POSITION SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY)
APP SENS 1 SENS GND
BLK WIRE
BLU WIRE
CAN-H
COMPUTER DATA LINES SYSTEM
ECM GND
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT)
FUSE
FUSE 10
FUSE BLOCK (J/B) (LOWER LEFT END OF DASH)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT W/ IGNITION RELAY 1 ENERGIZED
LT GRN WIRE
PNK CAN-L WIRE
PNK WIRE
PWR SPLY
RED WIRE
SENS GND (TPS)
SENS GND APP SENS 1
SENS PWR SPLY (TPS)
SENSOR 1
SENSOR 2
STOP LAMP SW
STOP LAMP SWITCH (TOP OF BRAKE PEDAL ASSEMBLY)
THROTTLE CONTROL MOTOR RELAY
THROTTLE CTRL MTR (CLS)
THROTTLE CTRL MTR (OPN)
THROTTLE POSI SENS 1
THROTTLE POSI SENS 2
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit, except hybrid (1 of 2) -> SENS GND APP SENS 1
