Infiniti QX60 I (2013-2016) right rear outer sonar sensor Wiring diagrams

This page contains all the electrical diagrams for the component. right rear outer sonar sensor, in which he is found in the car Infiniti QX60 I (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

right rear outer sonar sensor wiring diagram (1 of 8)

Infiniti QX60 I (2013-2016) right rear outer sonar sensor wiring diagram (1 of 8)

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FOL SNSR SIG FR SNSR GND GRN WIRE GRY WIRE IGN LED DISPLAY LEFT "C" PILLAR) LEFT REAR DOOR SPEAKER LEFT REAR DOOR TWEETER LEFT REAR OUTER SONAR SENSOR LT GRN WIRE NCA WIRE PNK WIRE PPL RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER RIGHT REAR DOOR TWEETER RIGHT REAR INNER SONAR SENSOR RIGHT REAR OUTER SONAR SENSOR RIL SNSR SIG RIR SNSR SIGNAL ROL SNSR SIG ROR SNSR SIGNAL SHIELD SONAR BUZZER SPKR PWR SPKR RR SIG SUBWOOFER V CAN-H V CAN-L W/ DRIVER ASSISTANCE SYSTEM WHT WIRE YEL WIRE

Go to component -> Bose radio circuit, except hybrid w/ navigation & surround (6 of 13) -> RIGHT REAR OUTER SONAR SENSOR

right rear outer sonar sensor wiring diagram (2 of 8)

Infiniti QX60 I (2013-2016) right rear outer sonar sensor wiring diagram (2 of 8)

A/C, AV SWITCH ASSEMBLY BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FOL SNSR SIG FOR SNSR SIG FR SNSR GND GRN WIRE GRY WIRE IGN LATE PRODUCTION LED DISPLAY LEFT FRONT OUTER SONAR SENSOR LEFT REAR INNER SONAR SENSOR LEFT REAR OUTER SONAR SENSOR LT BLU WIRE LT GRN WIRE PNK WIRE PPL RED WIRE RIGHT END OF DASH) RIGHT REAR INNER SONAR SENSOR RIGHT REAR OUTER SONAR SENSOR RIL SNSR SIG RIR SNSR SIGNAL ROL SNSR SIG ROR SNSR SIGNAL RR SNSR GND SHIELD SONAR BUZZER SONAR SYSTEM OFF SWITCH SPKR PWR SPKR RR SIG V CAN-H V CAN-L WHT WIRE YEL WIRE

Go to component -> Bose radio circuit, except hybrid w/ navigation w/o surround (6 of 10) -> RIGHT REAR OUTER SONAR SENSOR

right rear outer sonar sensor wiring diagram (3 of 8)

Infiniti QX60 I (2013-2016) right rear outer sonar sensor wiring diagram (3 of 8)

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FOL SNSR SIG FR SNSR GND GRN WIRE GRY WIRE IGN LEFT REAR DOOR SPEAKER LEFT REAR DOOR TWEETER LEFT REAR OUTER SONAR SENSOR LT BLU WIRE LT GRN WIRE NCA WIRE PNK WIRE PPL RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT FRONT TWEETER RIGHT REAR DOOR SPEAKER RIGHT REAR DOOR TWEETER RIGHT REAR INNER SONAR SENSOR RIGHT REAR OUTER SONAR SENSOR RIL SNSR SIG RIR SNSR SIGNAL ROL SNSR SIG ROR SNSR SIGNAL SHIELD SONAR BUZZER SPKR PWR SPKR RR SIG SUBWOOFER V CAN-H V CAN-L WHT WIRE YEL WIRE

Go to component -> Bose radio circuit, hybrid w/ navigation & surround (6 of 13) -> RIGHT REAR OUTER SONAR SENSOR

right rear outer sonar sensor wiring diagram (4 of 8)

Infiniti QX60 I (2013-2016) right rear outer sonar sensor wiring diagram (4 of 8)

A/C, AV SWITCH ASSEMBLY BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FOL SNSR SIG FOR SNSR SIG FR SNSR GND GRN WIRE GRY WIRE IGN LATE PRODUCTION LEFT FRONT OUTER SONAR SENSOR LEFT REAR OUTER SONAR SENSOR LT BLU WIRE LT GRN WIRE PNK WIRE PPL RED WIRE RIGHT REAR OUTER SONAR SENSOR ROL SNSR SIG ROR SNSR SIGNAL RR SNSR GND SHIELD SONAR BUZZER SPKR PWR SPKR RR SIG V CAN-H V CAN-L WHT WIRE YEL WIRE

Go to component -> Bose radio circuit, hybrid w/ navigation w/o surround (8 of 12) -> RIGHT REAR OUTER SONAR SENSOR

right rear outer sonar sensor wiring diagram (5 of 8)

Infiniti QX60 I (2013-2016) right rear outer sonar sensor wiring diagram (5 of 8)

A/C, AV SWITCH ASSEMBLY BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FOL SNSR SIG FOR SNSR SIG FR SNSR GND GRN WIRE GRY WIRE IGN LATE PRODUCTION LED DISPLAY LEFT FRONT OUTER SONAR SENSOR LEFT REAR INNER SONAR SENSOR LEFT REAR OUTER SONAR SENSOR LT BLU WIRE LT GRN WIRE PNK WIRE PPL RED WIRE RIGHT END OF DASH) RIGHT REAR INNER SONAR SENSOR RIGHT REAR OUTER SONAR SENSOR RIL SNSR SIG RIR SNSR SIGNAL ROL SNSR SIG ROR SNSR SIGNAL RR SNSR GND SHIELD SONAR BUZZER SONAR SYSTEM OFF SWITCH SPKR PWR SPKR RR SIG V CAN-H V CAN-L WHT WIRE YEL WIRE

Go to component -> Navigation circuit, except hybrid w/o surround (6 of 10) -> RIGHT REAR OUTER SONAR SENSOR

right rear outer sonar sensor wiring diagram (6 of 8)

Infiniti QX60 I (2013-2016) right rear outer sonar sensor wiring diagram (6 of 8)

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FOL SNSR SIG FR SNSR GND GRN WIRE GRY WIRE IGN LED DISPLAY LEFT "C" PILLAR) LEFT REAR DOOR SPEAKER LEFT REAR DOOR TWEETER LEFT REAR OUTER SONAR SENSOR LT GRN WIRE NCA WIRE PNK WIRE PPL RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER RIGHT REAR DOOR TWEETER RIGHT REAR INNER SONAR SENSOR RIGHT REAR OUTER SONAR SENSOR RIL SNSR SIG RIR SNSR SIGNAL ROL SNSR SIG ROR SNSR SIGNAL SHIELD SONAR BUZZER SPKR PWR SPKR RR SIG SUBWOOFER V CAN-H V CAN-L W/ DRIVER ASSISTANCE SYSTEM WHT WIRE YEL WIRE

Go to component -> Navigation circuit, except hybrid w/ surround (6 of 13) -> RIGHT REAR OUTER SONAR SENSOR

right rear outer sonar sensor wiring diagram (7 of 8)

Infiniti QX60 I (2013-2016) right rear outer sonar sensor wiring diagram (7 of 8)

A/C, AV SWITCH ASSEMBLY BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FOL SNSR SIG FOR SNSR SIG FR SNSR GND GRN WIRE GRY WIRE IGN LATE PRODUCTION LEFT FRONT OUTER SONAR SENSOR LEFT REAR OUTER SONAR SENSOR LT BLU WIRE LT GRN WIRE PNK WIRE PPL RED WIRE RIGHT REAR OUTER SONAR SENSOR ROL SNSR SIG ROR SNSR SIGNAL RR SNSR GND SHIELD SONAR BUZZER SPKR PWR SPKR RR SIG V CAN-H V CAN-L WHT WIRE YEL WIRE

Go to component -> Navigation circuit, hybrid w/o surround (8 of 12) -> RIGHT REAR OUTER SONAR SENSOR

right rear outer sonar sensor wiring diagram (8 of 8)

Infiniti QX60 I (2013-2016) right rear outer sonar sensor wiring diagram (8 of 8)

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FOL SNSR SIG FR SNSR GND GRN WIRE GRY WIRE IGN LEFT REAR DOOR SPEAKER LEFT REAR DOOR TWEETER LEFT REAR OUTER SONAR SENSOR LT BLU WIRE LT GRN WIRE NCA WIRE PNK WIRE PPL RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT FRONT TWEETER RIGHT REAR DOOR SPEAKER RIGHT REAR DOOR TWEETER RIGHT REAR INNER SONAR SENSOR RIGHT REAR OUTER SONAR SENSOR RIL SNSR SIG RIR SNSR SIGNAL ROL SNSR SIG ROR SNSR SIGNAL SHIELD SONAR BUZZER SPKR PWR SPKR RR SIG SUBWOOFER V CAN-H V CAN-L WHT WIRE YEL WIRE

Go to component -> Navigation circuit, hybrid w/ surround (6 of 13) -> RIGHT REAR OUTER SONAR SENSOR
