Infiniti QX60 I (2013-2016) pnk pnk distribution system pnk Wiring diagram
This page shows the only wiring diagram for the component.pnk pnk distribution system pnk, which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk pnk distribution system pnk (1 of 1)
ACC RLY OUT
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND INSTRUMENT CLUSTER)
BRN WIRE
CLOSE
EXCEPT HYBRID
EXCEPT HYBRID 4 2 W/O AROUND VIEW MONITOR SYSTEM LEFT DOOR MIRROR
EXCEPT HYBRID W/ AROUND VIEW MONITOR SYSTEM
FUSE
FUSE, FUSIBLE LINK BOX (LEFT SIDE OF ENGINE COMPT)
FUSIBLE LINK O
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT GRN WIRE
MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH (POWER MIRROR REMOTE CONTROL SWITCH)
PNK PNK DISTRIBUTION SYSTEM PNK WIRE
PNK WIRE
POWER
RED WIRE
RETRACTOR SWITCH
RIGHT DOOR MIRROR
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> PNK PNK DISTRIBUTION SYSTEM PNK WIRE
