Infiniti QX60 I (2013-2016) pnk immo start button ant b Wiring diagram
This page shows the only wiring diagram for the component.pnk immo start button ant b, which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk immo start button ant b (1 of 1)
60 59 CAN-H CAN-L PNK WIRE
BATT PWR F/L
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND INSTRUMENT CLUSTER)
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FUSE 13
FUSE 31
FUSE BLOCK (J/B) (LOWER LEFT END OF DASH)
FUSE, FUSIBLE LINK BOX (LEFT SIDE OF ENGINE COMPT)
FUSIBLE LINK O
GND 2
HOT AT ALL TIMES
HOT IN ON OR START
IMMO START BUTTON ANT A
IND
NATS ANTENNA AMP (AT PUSH-BUTTON IGNITION SWITCH)
PNK IMMO START BUTTON ANT B WIRE
PNK WIRE
PPL
PPL SECURITY IND
SECURITY
TAN WIRE
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
Go to component -> Immobilizer circuit -> PNK IMMO START BUTTON ANT B WIRE
