Infiniti QX60 I (2013-2016) navigation, body computer sound systems system Wiring diagram
This page shows the only wiring diagram for the component.navigation, body computer sound systems system, which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram navigation, body computer sound systems system (1 of 1)
ACCESSORY RELAY 1
ACCESSORY RELAY 2 (IN FUSE, RELAY BOX 1)
AIR CONDITIONING, INSTRUMENT CLUSTER, MIRRORS, NAVIGATION, SOUND SYSTEMS
BLK WIRE
BLU WIRE
BODY COMPUTER SYSTEM
COMPUTER DATA LINES, CRUISE CONTROL, AIR CONDITIONING, SEATS SYSTEMS
CRUISE CONTROL, ENGINE CONTROLS, AIR CONDITIONING SYSTEMS
DOOR LOCKS, ANTI-THEFT, WARNING, BODY COMPUTER SYSTEMS
EXTENDED STORAGE SWITCH
FROM BCM (BODY CONTROL MODULE) (DIAGRAM 3 OF 4)
FROM FUSE, FUSIBLE LINK BOX (DIAGRAM 1 OF 4)
FROM FUSIBLE LINK BOX (BATTERY) (DIAGRAM 1 OF 4)
FRONT BLOWER MOTOR RELAY
FRONT CONSOLE
FRONT POWER SOCKET (FOR CIGARETTE LIGHTER)
FUSE 1
FUSE 10
FUSE 11 FUSE 12
FUSE 13
FUSE 14 FUSE 9
FUSE 16
FUSE 19
FUSE 2
FUSE 20
FUSE 21
FUSE 25
FUSE 30
FUSE 4 FUSE 3 FUSE 15
GRN WIRE
GRY WIRE
IGNITION RELAY 2
LT GRN WIRE
NAVIGATION, BODY COMPUTER SOUND SYSTEMS SYSTEM
OUTLET MAIN SWITCH (DIAGRAM 3 OF 4)
PASSIVE RESTRAINTS, AIR CONDITIONING, WIPER/WASHER SYSTEMS
PNK WIRE
POWER SOCKET
PPL
REAR CARGO POWER SOCKET
REAR WINDOW DEFOGGER RELAY
RED WIRE
RIGHT END OF DASH)
SEATS, DOOR LOCKS, ANTI-THEFT, COMPUTER DATA LINES, TRANSMISSIONS SYSTEMS
TAN WIRE
TO FUSE 29 (DIAGRAM 3 OF 4)
TO PUSH BUTTON IGNITION SWITCH (DIAGRAM 3 OF 4)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (2 of 4) -> NAVIGATION, BODY COMPUTER SOUND SYSTEMS SYSTEM
