Infiniti QX60 I (2013-2016) lh mtr open noise shield latch rh mtr open shield Wiring diagram
This page shows the only wiring diagram for the component.lh mtr open noise shield latch rh mtr open shield, which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lh mtr open noise shield latch rh mtr open shield (1 of 1)
1 2 3 SHIELD
1 2 RH TOUCH SENS LH TOUCH SENS
13 14 15 16 17 18 19 20 21 22 23 24 (OR PPL) TOUCH SENS GND
25 26 27 28 29 30 31 32 33 34 35 36 37 38 B+
7 8 SHIELD
AUTOMATIC BACK DOOR CLOSE SWITCH
AUTOMATIC BACK DOOR CONTROL MODULE (LEFT REAR OF CARGO AREA)
AUTOMATIC BACK DOOR MAIN SWITCH
AUTOMATIC BACK DOOR SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CIRCUIT BREAKER
COMPUTER DATA LINES SYSTEM
EXCEPT HYBRID HYBRID
FUSE, FUSIBLE LINK BOX (LEFT SIDE OF ENGINE COMPT)
GRY WIRE
HOT AT ALL TIMES FUSIBLE LINK N
LATCH MTR OPEN GND
LEFT SPINDLE UNIT (TOP OF LEFT "D" PILLAR)
LH MTR CLOSE
LH MTR OPEN NOISE SHIELD LATCH RH MTR OPEN SHIELD
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
RH MTR CLOSE BUZZER LATCH MTR CLOSE
RIGHT END OF DASH)
RIGHT SPINDLE UNIT (TOP OF RIGHT "D" PILLAR)
SHIELD
SHIELD CAN SHIELD LH POWER RH POWER GND HALL DRIVER SW INSIDE CLOSE SW CAN-H
SPINDLE MOTOR
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Automatic back door circuit (1 of 2) -> LH MTR OPEN NOISE SHIELD LATCH RH MTR OPEN SHIELD
