Infiniti QX60 I (2013-2016) left front outside Wiring diagram
This page shows the only wiring diagram for the component.left front outside, which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front outside (1 of 1)
136 139 ROOM LAMP CONT BAT-POWER F/L BAT BCM FUSE BATTERY SAVER OUTPUT
82 96 94 93 97 RL DOOR SW DR DOOR SW AS DOOR SW RR DOOR SW BACK DOOR SW
AUTOMATIC BACK DOOR CLOSE SWITCH
BACK DOOR LOCK ASSEMBLY (LOWER LEFT SIDE OF BACK DOOR)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
BRN WIRE
DIODE-2 (RIGHT CENTER OF BACK DOOR)
FUSE 1
FUSE BLOCK (J/B) (LOWER LEFT END OF DASH)
GRN WIRE
HANDLE ASSEMBLY
HOT AT ALL TIMES
LEFT FOOT LAMP
LEFT FRONT DOOR SWITCH (AT LEFT FRONT "B" PILLAR)
LEFT FRONT OUTSIDE
LEFT FRONT STEP LAMP
LEFT REAR DOOR SWITCH (AT LEFT REAR "C" PILLAR)
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
RIGHT FOOT LAMP
RIGHT FRONT DOOR SWITCH (AT RIGHT FRONT "B" PILLAR)
RIGHT FRONT OUTSIDE
RIGHT FRONT STEP LAMP
RIGHT REAR DOOR SWITCH (AT RIGHT REAR "C" PILLAR)
STEP LAMP CONT
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> LEFT FRONT OUTSIDE
