Infiniti QX60 I (2013-2016) left front door switch Wiring diagrams
This page contains all the electrical diagrams for the component. left front door switch, in which he is found in the car Infiniti QX60 I (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front door switch (1 of 2)
A/L SIGNAL
AS DOOR SW
BAT BCM FUSE
BAT PWR (F/L)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM)
BRAKE IND
CAN L
CAN-H
COMBI SW IN 1
COMBI SW IN 2
COMBI SW IN 3
COMBI SW IN 4
COMBI SW IN 5
COMBI SW OUT 1
COMBI SW OUT 2
COMBI SW OUT 3
COMBI SW OUT 4
COMBI SW OUT 5
COMBINATION METER
COMBINATION SWITCH (LIGHTING, TURN SIGNAL SWITCH)
COMPUTER DATA LINES SYSTEM
DR DOOR SW
FOG LIGHT IND
FUSE 1
FUSE 13
FUSE 31
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK BOX
FUSIBLE LINK O
GND RF A/L
GRN WIRE
HIGH BEAM (BLUE) IND
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN USM OUT 1
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
LIGHT IND (HYBRID)
LT BLU WIRE
LT GRN WIRE
OPTICAL SENSOR
PARKING BRAKE SWITCH
PNK WIRE
PPL
RED WIRE
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR SWITCH
RL DOOR SW
RR DOOR SW
TAN WIRE
UNIFIED METER CONTROL UNIT
WHT WIRE
Go to component -> Headlights circuit, w/ drl (1 of 2) -> LEFT FRONT DOOR SWITCH
Wiring diagram left front door switch (2 of 2)
A/L SIGNAL
AS DOOR SW
BAT BCM FUSE
BAT PWR (F/L)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM)
BRAKE IND
CAN L
CAN-H
COMBI SW IN 1
COMBI SW IN 2
COMBI SW IN 3
COMBI SW IN 4
COMBI SW IN 5
COMBI SW OUT 1
COMBI SW OUT 2
COMBI SW OUT 3
COMBI SW OUT 4
COMBI SW OUT 5
COMBINATION METER
COMBINATION SWITCH (LIGHTING, TURN SIGNAL SWITCH)
COMPUTER DATA LINES SYSTEM
DR DOOR SW
FOG LIGHT IND
FUSE 1
FUSE 13
FUSE 31
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK BOX
FUSIBLE LINK O
GND RF A/L
GRN WIRE
HIGH BEAM (BLUE) IND
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN USM OUT 1
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
LIGHT IND
LT BLU WIRE
LT GRN WIRE
OPTICAL SENSOR
PARKING BRAKE SWITCH
PNK WIRE
PPL
RED WIRE
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR SWITCH
RL DOOR SW
RR DOOR SW
TAN WIRE
UNIFIED METER CONTROL UNIT
WHT WIRE
Go to component -> Headlights circuit, w/o drl (1 of 2) -> LEFT FRONT DOOR SWITCH
