Infiniti QX60 I (2013-2016) headlights engine controls system system wiring diagram
This page shows the only wiring diagram for the component.headlights engine controls system system, which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
headlights engine controls system system wiring diagram (1 of 1)
A/C RELAY
ANTI-LOCK BRAKES, ELECTRONIC POWER STEERING SYSTEMS
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
ECM RELAY
ELECTRONIC POWER STEERING SYSTEM
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS, AIR CONDITIONING SYSTEMS
ENGINE CONTROLS, COOLING FANS SYSTEMS
EXTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM
EXTERIOR LIGHTS, TRANSMISSIONS SYSTEMS
FROM FUSIBLE LINK BOX (BATTERY) (DIAGRAM 1 OF 4)
FROM IGNITION RELAY 1 (DIAGRAM 4 OF 4)
FRONT FOG LAMP RELAY
FRONT WIPER HIGH RELAY
FRONT WIPER RELAY
FUEL PUMP RELAY
FUSE 41
FUSE 42
FUSE 43 FUSE 56 10
FUSE 44 FUSE 48
FUSE 45
FUSE 46
FUSE 49
FUSE 50 FUSE 47
FUSE 51
FUSE 52
FUSE 53
FUSE 55
FUSE 71 FUSIBLE LINK R FUSE 72
FUSE 73
FUSE 74 FUSE 75
FUSE 81
FUSIBLE LINK T FUSIBLE LINK Q
FUSIBLE LINK V
GRN WIRE
HEADLAMP HIGH RELAY
HEADLAMP LOW RELAY
HEADLIGHTS ENGINE CONTROLS SYSTEM SYSTEM
HIGH VOLTAGE FUSE, FUSIBLE LINK, RELAY BOX (LEFT REAR OF ENGINE COMPT)
IGNITION RELAY 1
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PNK WIRE
PPL
RED WIRE
SEATS SEATS SYSTEM SYSTEM
SELF SHUT OFF RELAY
STARTER RELAY
TAIL LAMP RELAY
TAN WIRE
THROTTLE CONTROL MOTOR RELAY
TO (LEFT REAR FUSE OF ENGINE BLOCK (J/B) COMPT) (DIAGRAM 3 OF 4)
TO FUSE 47 (DIAGRAM 4 OF 4)
TO FUSE BLOCK (J/B) (DIAGRAM 2 OF 4) TO FUSE, FUSIBLE LINK BOX (DIAGRAM 1 OF 4)
TRANSMISSIONS SYSTEM
WHT WIRE
WIPER/WASHER, BODY COMPUTER SYSTEMS
YEL WIRE
Go to component -> Power distribution circuit, hybrid (4 of 4) -> HEADLIGHTS ENGINE CONTROLS SYSTEM SYSTEM
