Infiniti QX60 I (2013-2016) fusible link o of engine compt) Wiring diagram
This page shows the only wiring diagram for the component.fusible link o of engine compt), which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fusible link o of engine compt) (1 of 1)
139 131 BAT PWR F/L BAT BCM FUSE
39 38 1 2 PNK WIRE
82 93 94 96 RL DOOR SW RR DOOR SW AS DOOR SW DR DOOR SW
A/L SIGNAL GND RF A/L
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND INSTRUMENT CLUSTER)
BRAKE IND
COMBINATION METER
COMBINATION SWITCH (LIGHTING, TURN SIGNAL SWITCH)
COMPUTER DATA LINES SYSTEM
END OF DASH)
FOG LIGHT IND
FUSE
FUSE 13
FUSE 31
FUSE, FUSIBLE LINK BOX (LEFT SIDE
FUSIBLE LINK O OF ENGINE COMPT)
GRN WIRE
HIGH BEAM (BLUE) IND
HOT AT ALL TIMES
HOT W/ IGNITION RELAY 2 ENERGIZED FUSE BLOCK (J/B) (LOWER LEFT
LEFT FRONT DOOR SWITCH (AT LEFT "B" PILLAR)
LEFT REAR DOOR SWITCH (AT LEFT "C" PILLAR)
LIGHT IND (HYBRID)
LT BLU WIRE
LT GRN (OR PPL) WIRE
LT GRN WIRE
OPTICAL SENSOR (TOP RIGHT SIDE OF DASH)
PARKING BRAKE SWITCH
PNK PNK WIRE
PNK WIRE
PPL
RED WIRE
RIGHT FRONT DOOR SWITCH (AT RIGHT "B" PILLAR)
RIGHT REAR DOOR SWITCH (AT RIGHT "C" PILLAR)
TAN WIRE
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
Go to component -> Headlights circuit, without drl (1 of 2) -> FUSIBLE LINK O OF ENGINE COMPT)
