Infiniti QX60 I (2013-2016) from fuse, fusible link box pnk wiring diagram
This page shows the only wiring diagram for the component.from fuse, fusible link box pnk, which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
from fuse, fusible link box pnk wiring diagram (1 of 1)
+B OUTPUT 1 SW INPUT LED GND
1 2 3 4 5 6 7 8 OUTPUT 2
ACC/ ON IND
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
ENG
EXTERIOR LIGHTS, MIRRORS, SEATS, NAVIGATION, SOUND SYSTEMS
FROM FUSE BLOCK J/B (DIAGRAM 2 OF 4)
FROM FUSE, FUSIBLE LINK BOX PNK WIRE
FROM IGNITION RELAY 2 (DIAGRAM 2 OF 4)
FUSE 28
FUSE 29
FUSE 31
FUSE 32
GRN WIRE
IGN ELEC RLY OUT
ILLUMINATION
INVERTER UNIT (IF EQUIPPED)
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
J/C
LED
LEFT "C" PILLAR)
LT GRN WIRE
MAIN SWITCH
PNK WIRE
PUSH BUTTON IGNITION SWITCH
PUSH SWITCH
QUARTERPANEL)
RED WIRE
RIGHT END OF DASH)
RLY OUT
SEATS SYSTEM
SHIELD
SUPPLEMENTAL RESTRAINTS SYSTEM
TAN WIRE
TO FUSE BLOCK (J/B) (DIAGRAM 2 OF 4)
WHT WIRE
Go to component -> Power distribution circuit, except hybrid (3 of 4) -> FROM FUSE, FUSIBLE LINK BOX PNK WIRE
