Infiniti QX60 I (2013-2016) from fuse, fusible link box Wiring diagram
This page shows the only wiring diagram for the component.from fuse, fusible link box, which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram from fuse, fusible link box (1 of 1)
+B OUTPUT 1 SW INPUT LED GND
1 2 3 4 5 6 7 8 OUTPUT 2
ACC/ ON IND
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND INSTRUMENT CLUSTER)
BRN WIRE
ENG RLY SW OUT
EXTERIOR LIGHTS, MIRRORS, SEATS, NAVIGATION, SOUND SYSTEMS
FROM FUSE BLOCK J/B (DIAGRAM 2 OF 4)
FROM FUSE, FUSIBLE LINK BOX
FROM IGNITION RELAY 2 (DIAGRAM 2 OF 4)
FUSE 26
FUSE 28
FUSE 29
FUSE 31 FUSE 32
FUSE 33
FUSE BLOCK (J/B)
GRN WIRE
IGN ELEC BLOWER RLY FAN OUT RLY OUT
ILLUMINATION
INVERTER UNIT (BASE OF LEFT "D" PILLAR)
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
J/C
LED
LEFT "C" PILLAR)
LT GRN WIRE
MAIN SWITCH
PNK WIRE
PUSH BUTTON IGNITION SWITCH
PUSH SWITCH
QUARTERPANEL)
RED WIRE
RIGHT END OF DASH)
SEATS SYSTEM
SHIELD
SUPPLEMENTAL RESTRAINTS SYSTEM
TAN WIRE
TO FUSE BLOCK (J/B) (DIAGRAM 2 OF 4)
TO FUSE, FUSIBLE LINK BOX (DIAGRAM 1 OF 4)
TO TO FUSE FUSE BLOCK (J/B) BLOCK (J/B) (DIAGRAM (DIAGRAM 2 OF 4) 2 OF 4)
WHT WIRE
Go to component -> Power distribution circuit, hybrid (3 of 4) -> FROM FUSE, FUSIBLE LINK BOX
