Infiniti QX60 I (2013-2016) except hybrid hybrid except hybrid w/ around view 2 3 Wiring diagram
This page shows the only wiring diagram for the component.except hybrid hybrid except hybrid w/ around view 2 3, which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram except hybrid hybrid except hybrid w/ around view 2 3 (1 of 1)
20 21 GND (SENS GND)
25 26 27 28 29 30 BAT (PTC) TELESCOPIC MTR (BACK) PPL
8 9 10 11 UART (TX/RX)
AUTOMATIC DRIVE POSITIONER CONTROL UNIT (RIGHT CENTER OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
CHANGE OVER SWITCH
DEFOGGER SYSTEM
DOWN UP
EXCEPT HYBRID HYBRID EXCEPT HYBRID W/ AROUND VIEW 2 3
FUSE 1
FUSE BLOCK (J/B) (LOWER LEFT END OF DASH)
GRN WIRE
HOT AT ALL TIMES
LEFT DOOR MIRROR
LEFT DOWN RIGHT UP
LEFT RIGHT
LT BLU WIRE
LT GRN WIRE
MEMORY POWER TILT, POWER TELESCOPIC CIRCUIT
MIRROR MTR (LH COMM (DWN, RH))
MIRRORS, NAVIGATION NAVIGATION SYSTEM SYSTEMS
MIRRORS, NAVIGATION SYSTEMS
MONITOR SYSTEM EXCEPT HYBRID W/O AROUND VIEW MONITOR SYSTEM
NAVIGATION SYSTEM
PNK MIRROR MTR (RH VERT (UP)) MIRROR MTR (RH HRZ (LH)) WIRE
PNK WIRE
PPL
RED WIRE
RIGHT DOOR MIRROR
RIGHT LEFT
SHIELD
SIDE CAMERA
TAN WIRE
TELESCOPIC SW (BACK)
TELESCOPIC SW (FRONT)
TILT MTR (DOWN) STRG MTR COMM (UP/FWD) GND (PWR)
TILT SW (DOWN)
WHT WIRE
YEL WIRE
Go to component -> Memory seat & mirrors circuit (1 of 3) -> EXCEPT HYBRID HYBRID EXCEPT HYBRID W/ AROUND VIEW 2 3
