Infiniti QX60 I (2013-2016) engine controls system transmissions, exterior lights systems wiring diagram
This page shows the only wiring diagram for the component.engine controls system transmissions, exterior lights systems, which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
engine controls system transmissions, exterior lights systems wiring diagram (1 of 1)
A/C RELAY
AIR CONDITIONING, COOLING FANS SYSTEMS
ANTI-LOCK BRAKES, ELECTRONIC POWER STEERING SYSTEMS
BLK WIRE
BLU WIRE
BRN WIRE
CRUISE CONTROL, TRANSMISSIONS SYSTEMS
ECM RELAY THROTTLE CONTROL MOTOR RELAY
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS SYSTEM TRANSMISSIONS, EXTERIOR LIGHTS SYSTEMS
EXTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM
FROM FUSE, FUSIBLE LINK BOX (DIAGRAM 1 OF 4)
FROM FUSIBLE LINK BOX (BATTERY) (DIAGRAM 1 OF 4)
FROM IGNITION RELAY 1 (DIAGRAM 4 OF 4)
FRONT FOG LAMP RELAY
FRONT WIPER HIGH RELAY
FRONT WIPER RELAY
FUEL PUMP RELAY
FUSE 41
FUSE 42
FUSE 43 FUSE 56
FUSE 44 FUSE 48
FUSE 45
FUSE 46
FUSE 47
FUSE 49
FUSE 50
FUSE 51
FUSE 52
FUSE 53
FUSE 55
GRN WIRE
GRY WIRE
HEADLAMP HIGH RELAY
HEADLAMP LOW RELAY
HEADLIGHTS, (LEFT REAR EXTERIOR LIGHTS, OF ENGINE COMPT) INTERIOR LIGHTS SYSTEMS
IGNITION RELAY 1
LT BLU WIRE
LT GRN WIRE
PPL
RED WIRE
STARTER RELAY
TAIL LAMP RELAY
TO FUSE 47 (DIAGRAM 4 OF 4)
TRANSMISSIONS SYSTEM
TRANSMISSIONS, STARTING/ CHARGING SYSTEMS
WHT WIRE
WIPER/WASHER, BODY COMPUTER SYSTEMS
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (4 of 4) -> ENGINE CONTROLS SYSTEM TRANSMISSIONS, EXTERIOR LIGHTS SYSTEMS
