Infiniti QX60 I (2013-2016) engine controls, air conditioning, cruise control, body computer systems Wiring diagram
This page shows the only wiring diagram for the component.engine controls, air conditioning, cruise control, body computer systems, which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine controls, air conditioning, cruise control, body computer systems (1 of 1)
ACCESSORY RELAY 1
ACCESSORY RELAY 2 (IN FUSE, RELAY BOX)
AIR CONDITIONING, PASSIVE RESTRAINTS, WIPER/WASHER, ANTI-THEFT, SEATS SYSTEMS
BLK WIRE
BLU WIRE
BODY COMPUTER SYSTEM
DOOR LOCKS, ANTI-THEFT, BODY COMPUTER SYSTEMS
DOOR LOCKS, ANTI-THEFT, WARNING, BODY COMPUTER SYSTEMS
ENGINE CONTROLS, AIR CONDITIONING, CRUISE CONTROL, BODY COMPUTER SYSTEMS
EXTENDED STORAGE SWITCH
FROM BCM (BODY CONTROL MODULE) (DIAGRAM 3 OF 4)
FROM FUSE, FUSIBLE LINK BOX (DIAGRAM 1 OF 4)
FROM HIGH VOLTAGE FUSE, FUSIBLE LINK, RELAY BOX (DIAGRAM 4 OF 4)
FRONT BLOWER MOTOR RELAY
FRONT CONSOLE
FRONT POWER SOCKET (FOR CIGARETTE LIGHTER)
FUSE 1
FUSE 10 FUSE 15
FUSE 11 FUSE 12
FUSE 13
FUSE 14
FUSE 16
FUSE 19
FUSE 2
FUSE 20
FUSE 21
FUSE 25
FUSE 3 FUSE 4
FUSE 30
FUSE 9
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
IGNITION RELAY 2
LT GRN WIRE
NAVIGATION, SOUND SYSTEMS
NCA WIRE
OUTLET MAIN SWITCH (DIAGRAM 3 OF 4)
PNK WIRE
POWER SOCKET
PPL
REAR CARGO POWER SOCKET
REAR WINDOW DEFOGGER RELAY
RED WIRE
RIGHT END OF DASH)
TAN WIRE
TO FUSE 29 (DIAGRAM 3 OF 4)
TO PUSH BUTTON IGNITION SWITCH (DIAGRAM 3 OF 4)
WHT WIRE
WIPER/WASHER, BODY COMPUTER SYSTEMS
YEL WIRE
Go to component -> Power distribution circuit, hybrid (2 of 4) -> ENGINE CONTROLS, AIR CONDITIONING, CRUISE CONTROL, BODY COMPUTER SYSTEMS
