Infiniti QX60 I (2013-2016) eng coolant Wiring diagram
This page shows the only wiring diagram for the component.eng coolant, which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram eng coolant (1 of 1)
1 2 3 GND SIG PWR
A/C COMPRESSOR (LOWER LEFT FRONT OF ENGINE)
A/C RELAY
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
COOLING FAN CONTROL MODULE (ON COOLING FAN MOTORS ASSEMBLY)
COOLING FAN MOTOR 1 (BEHIND LEFT SIDE OF RADIATOR)
COOLING FAN MOTOR 2 (BEHIND RIGHT SIDE OF RADIATOR)
COOLING FAN RELAY (IN FUSE, FUSIBLE LINK BOX)
DISTRIBUTION MODULE ENGINE ROOM) (LEFT REAR OF ENGINE COMPT)
ECM (ENGINE CONTROL MODULE) (LEFT SIDE OF ENGINE COMPT)
ENG COOLANT
ENGINE COOLANT TEMPERATURE
FUSE 48
FUSE 53
FUSE 56
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGNITION RELAY 1
IPDM E/R (INTELLIGENT POWER
LT BLU WIRE
LT GRN WIRE
PNK 1 2 WIRE
PNK WIRE
POWER SUPPLY
PPL
RED WIRE
REFRIGERANT PRESSURE SENSOR (TOP OF A/C REFRIGERANT TANK)
SENS GND
SENSOR (REAR OF LEFT CYLINDER BANK)
SENSOR PWR SPLY
SRMS GND
TEMP SENS
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit, except hybrid (4 of 4) -> ENG COOLANT
