Infiniti QX60 I (2013-2016) electronic ctrl eng sol vlv vias ctrl sol valve 1 vias ctrl sol valve 2 Wiring diagram

29 30 PPL BLK WIRE BLU WIRE BRN WIRE ELECTRONIC CTRL ENG SOL VLV VIAS CTRL SOL VALVE 1 VIAS CTRL SOL VALVE 2 ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT) FUEL INJ 1 THROTTLE CTRL MTR RLY FUEL INJECTOR 3 (RIGHT SIDE OF INTAKE MANIFOLD) FUEL INJECTOR 4 (LEFT SIDE OF INTAKE MANIFOLD) FUEL INJECTOR 5 (RIGHT SIDE OF INTAKE MANIFOLD) GRN WIRE GRY WIRE LOOP WIRE LT BLU WIRE LT GRN WIRE NCA WIRE PLUG SPARK PPL PPL ECM RLY (SELF SHUT-OFF) PPL PPL PWR SPLY FOR ECM RED WIRE REFRIGERANT PRESS SENS SENS GND PPL SENS GROUND SENS PWR SPLY INTAKE VLV TIMING CTRL SOL VLV SPARK PLUG THROTTLE POSITION SENS 1 THROTTLE POSITION SENS 2 SENS PWR SPLY WHT WIRE YEL WIRE
