Infiniti QX60 I (2013-2016) can-l gnd can-h Wiring diagram
This page shows the only wiring diagram for the component.can-l gnd can-h, which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram can-l gnd can-h (1 of 1)
1 2 3 PNK WIRE
59 60 PNK CAN-L CAN-H WIRE
BATT CURRENT SENS
BATT TEMP SENS
BCM (BODY CONTROL MODULE) (BEHIND INSTRUMENT CLUSTER)
BLK WIRE
BLU WIRE
BRAKE VACUUM SENSOR (ON BRAKE VACUUM BOOSTER)
BRK VACCUM SW
BRN WIRE
CAN-L GND CAN-H
COMPUTER DATA LINES SYSTEM
FUSE 46
FUSE, FUSIBLE LINK BOX (LEFT SIDE OF ENGINE COMPT)
FUSIBLE LINK K
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY 1 ENERGIZED
HPCM (UNDER LEFT FRONT
LT BLU WIRE
LT GRN WIRE
OF CENTER CONSOLE)
P/N SIG
PNK 1 2 WIRE
PNK WIRE
PPL
PWR SPLY
RED WIRE
SENS GND
SENS PWR SPLY
SHIELD
SHIELD 14 15 16 17 18
SHIFT N/P
STARTER RELAY
STARTER RELAY OUT
STR MTR STATUS SIG
TAN WIRE
TRANSMISSION RANGE SWITCH (LEFT SIDE OF TRANSMISSION)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.5l hybrid, hybrid system circuit (2 of 6) -> CAN-L GND CAN-H
