Infiniti QX60 I (2013-2016) brk pdl pos sw 97 98 hev can-h hev can-l Wiring diagram
This page shows the only wiring diagram for the component.brk pdl pos sw 97 98 hev can-h hev can-l, which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brk pdl pos sw 97 98 hev can-h hev can-l (1 of 1)
2 3 4 PNK WIRE
5 6 PNK WIRE
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH (TOP OF BRAKE PEDAL ASSEMBLY)
BRK PDL POS SW 97 98 HEV CAN-H HEV CAN-L
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FUEL LEVEL SENSOR
FUEL PUMP
FUSE
FUSE 30
FUSE BLOCK (J/B)
GND 2
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
HPCM (UNDER LEFT FRONT OF CENTER CONSOLE)
IGN
INSTRUMENT CLUSTER SYSTEM
LT BLU WIRE
LT GRN WIRE
MALFUNCTION INDICATOR LAMP (MIL)
PNK WIRE
PPL
RED WIRE
SHIELD
STOP LAMP SWITCH (TOP OF BRAKE PEDAL ASSEMBLY)
TAN WIRE
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.5l hybrid, engine controls circuit (4 of 6) -> BRK PDL POS SW 97 98 HEV CAN-H HEV CAN-L
