Infiniti QX60 I (2013-2016) bat bcm fuse bat pwr f/l Wiring diagram
This page shows the only wiring diagram for the component.bat bcm fuse bat pwr f/l, which is found in the car Infiniti QX60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bat bcm fuse bat pwr f/l (1 of 1)
AV CONTROL UNIT
BAT BCM FUSE BAT PWR F/L
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND INSTRUMENT CLUSTER)
BRN WIRE
CAN-H HEV CAN-H
CAN-L HEV CAN-L
EXCEPT HYBRID
FUSE
FUSE 48
FUSIBLE FUSIBLE LINK O LINK BOX (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BLOCK FUSE 1 (J/B) (LOWER LEFT END OF DASH)
HOT W/ IGNITION RELAY 1 ENERGIZED
HYDRID
LEFT BACKUP LAMP
LT GRN WIRE
PNK COMPUTER DATA LINES SYSTEM CAN-L CAN-H WIRE
PNK COMPUTER DATA LINES WIRE
R RANGE SW
RED WIRE
REV LMP OUT
REV SIG
RIGHT BACKUP LAMP
RIGHT END OF DASH)
SYSTEM
TRANSMISSION CONTROL MODULE (TCM) (LEFT FRONT OF ENGINE COMPT)
TRANSMISSION RANGE SWITCH (LEFT SIDE OF TRANSMISSION)
WHT WIRE
Go to component -> Backup lamps circuit -> BAT BCM FUSE BAT PWR F/L
