Infiniti QX60 I (2013-2016) (base of Wiring diagrams
This page contains all the electrical diagrams for the component. (base of, in which he is found in the car Infiniti QX60 I (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
(base of wiring diagram (1 of 2)
A/C, AV SWITCH ASSEMBLY
AV CONTROL UNIT
BLK WIRE
BLU WIRE
BLUETOOTH CONTROL UNIT (LEFT REAR OF CARGO AREA)
GRN WIRE
HEADREST DISPLAY UNIT (DRIVER SEAT)
HEADREST DISPLAY UNIT (PASSENGER SEAT)
LT BLU WIRE
LT GRN WIRE
M CAN-H
M CAN-L
M CAN-L M CAN-H
PNK WIRE
RED WIRE
SHIELD
SHIELD PNK WIRE
SHIELD SHIELD 4 3 2
SHIELD SHIELD 5 16 15
TAN WIRE
TRM
WHT WIRE
Go to component -> Computer data lines circuit, hybrid with memory with icc (2 of 4) -> (BASE OF
(base of wiring diagram (2 of 2)
A/C, AV SWITCH ASSEMBLY
AV CONTROL UNIT
BLK WIRE
BLU WIRE
BLUETOOTH CONTROL UNIT (LEFT REAR OF CARGO AREA)
GRN WIRE
HEADREST DISPLAY UNIT (DRIVER SEAT)
HEADREST DISPLAY UNIT (PASSENGER SEAT)
LT BLU WIRE
LT GRN WIRE
M CAN-H
M CAN-L
M CAN-L M CAN-H
PNK WIRE
RED WIRE
SHIELD
SHIELD PNK WIRE
SHIELD SHIELD 4 3 2
SHIELD SHIELD 5 16 15
TAN WIRE
TRM
WHT WIRE
Go to component -> Computer data lines circuit, hybrid with memory without icc (2 of 4) -> (BASE OF
