Infiniti QX56 II (2010-2013) Charging circuit

ALTERNATOR BATTERY BATTERY TERMINAL W/ FUSIBLE LINK BLK WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE CHARGE IND COMBINATION METER COMPUTER DATA LINES SYSTEM CPU IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) FUSE 3 FUSE 32 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX FUSIBLE LINK A FUSIBLE LINK E GRY WIRE HOT W/ IGNITION RELAY 1 ENERGIZED NCA WIRE ORG/BLU WIRE PNK WIRE RED WIRE WHT WIRE
