Trailer tow circuit for Infiniti QX56 II (2010-2013)

BAT (F/L) BAT FUSE BCM (BODY CONTROL MODULE) (UNDER LEFT SIDE OF DASH) BLK WIRE BLU WIRE BLU/WHT WIRE BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM FUSE 10 FUSE 3 FUSE 6 FUSE 84 FUSE 86 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK HOLDER 5 FUSE, FUSIBLE LINK, RELAY BOX FUSIBLE LINK V GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START INT ROOM LAMP PWR SPLY LH CONT TRAILER TURN SIG LT GRN WIRE OPTION CONNECTOR 1 ORG/BLU WIRE PNK WIRE PPL RED WIRE RED/GRN WIRE RH CONT TRAILER TURN SIG ROOM LAMP TIMER CONT TRAILER POWER RELAY TRAILER TAIL LAMP RELAY WHT/RED WIRE YEL WIRE YEL/BLK WIRE

BACKUP LAMPS CIRCUIT BATTERY TERMINAL W/ FUSIBLE LINK BLK WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE COMPUTER DATA LINES SYSTEM ELECTRIC BRAKE OPTION CONNECTOR FUSE 46 FUSE 55 FUSE 7 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX FUSIBLE LINK F FUSIBLE LINK K FUSIBLE LINK N GRN/BLK WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON OR START IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LEFT TRAILER TURN SIGNAL LAMP RELAY PNK WIRE PPL RED WIRE RED/GRN WIRE RIGHT TRAILER TURN SIGNAL LAMP RELAY STOP LAMP SWITCH TAIL LAMP RELAY TRAILER OPTION CONNECTOR WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE
