Instrument illumination circuit for Infiniti QX56 I facelift (2007-2010)

+IG BLK WIRE BLU WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) CAN-H CAN-L CAN-H COMB SW IN 1 COMB SW IN 2 COMB SW IN 3 COMB SW IN 4 COMB SW IN 5 COMB SW OUT 1 COMB SW OUT 2 COMB SW OUT 3 COMB SW OUT 4 COMB SW OUT 5 COMBINATION SWITCH COMPUTER DATA LINES SYSTEM CPU TAIL/L RLY FUSE 36 FUSE FUSE (RIGHT REAR CORNER OF ENGINE COMPT) FUSE, FUSIBLE LINK BOX (RIGHT REAR OF ENGINE COMPT) FUSE/ RELAY BOX FUSIBLE LINK F GND BAT (F/L) GND PWR GND SIG GRN/BLK WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON OR START IGN SW IGNITION RELAY INPUT 1 INPUT 2 INPUT 3 INPUT 4 INPUT 5 LT BLU WIRE ORG/BLK WIRE OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4 OUTPUT 5 PNK CAN-L WIRE PNK DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) WIRE PNK WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE TAIL LAMP RELAY VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE

A/C AUTO AMPLIFIER A/C, AV SWITCH ASSEMBLY A/T DEVICE (AT BASE OF SHIFTER ASSEMBLY) ASCD STEERING SWITCH AV ILL+ CONTROL UNIT BLK WIRE BLU WIRE BRN WIRE CLOCK COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM CONSOLE BOX ILLUMINATION DOOR MIRROR REMOTE CONTROL SWITCH DVD PLAYER (W/ DVD ENTER- TAINMENT SYSTEM) ILL+ ELECTRIC BRAKE (PRE- WIRING) TOW MODE SWITCH FRONT ROOM/MAP LAMP ASSEMBLY FUSE 14 FUSE 19 FUSE BLOCK (J/B) (RIGHT SIDE OF DASH) GLOVE BOX LAMP) HAZARD SWITCH HEADLAMP AIMING SWITCH HOT AT ALL TIMES HOT IN ON OR START ILLUMINATION METER LEFT FRONT HEATED SEAT SWITCH LEFT REAR HEATED SEAT SWITCH ORG/ WIRE PEDAL ADJUSTING SWITCH PNK WIRE POWER LIFTGATE SWITCH REAR ILL+ AUDIO REMOTE CONTROL GND UNIT REAR POWER VENT WINDOW SWITCH REAR SONAR SYSTEM OFF SWITCH RED WIRE RED/BLU WIRE RESISTOR RIGHT FRONT HEATED SEAT SWITCH RIGHT REAR HEATED SEAT SWITCH SHIFT SWITCH STEERING WHEEL/ AUDIO CONTROL SWITCH UNIFIED METER CONTROL UNIT VDC OFF SWITCH W/ 4-WHEEL DRIVE YEL WIRE
