Courtesy lamps circuit for Infiniti QX56 I (2004-2007)

56 57 62 63 67 70 BAT SAVER BAT (FUSE) STEP LAMP ROOM LAMP GND BAT (F/L) BACK DOOR SWITCH BETWEEN FULL STROKE, N BETWEEN FULL STROKE, N BLK WIRE BLK/RED WIRE BLU WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/WHT WIRE CARGO LAMP DOOR ON FULL STROKE FULL STROKE FUSE 22 FUSE BLOCK (J/B) (RIGHT SIDE OF DASH) FUSE 19 FUSE, FUSIBLE LINK BOX (LEFT REAR OF ENGINE COMPT, NEAR BATTERY) FUSE, RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPT) FUSE 59 FUSIBLE LINK F GLASS HATCH AJAR SWITCH (LOW CENTER OF BACK DOOR) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION KEYHOLE ILLUMINATION KEY SWITCH, KEY LOCK SOLENOID (ON RIGHT SIDE OF STEERING COLUMN) LEFT FOOT LAMP LEFT FRONT DOOR KEY CYLINDER SWITCH LEFT FRONT DOOR SWITCH (LEFT "B" PILLAR) LEFT FRONT STEP LAMP LEFT REAR DOOR SWITCH (LEFT "C" PILLAR) LEFT REAR STEP LAMP LOCK SWITCH UNLOCK SWITCH LT BLU WIRE LT GRN/WHT WIRE MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH OFF PNK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FOOT LAMP RIGHT FRONT STEP LAMP RIGHT POWER WINDOW, DOOR LOCK/UNLOCK SWITCH RIGHT REAR DOOR SWITCH (RIGHT "C" PILLAR) RIGHT REAR STEP LAMP WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/PPL WIRE YEL WIRE YEL/RED WIRE

BLK WIRE BLU WIRE DOOR FRONT ROOM/ MAP LAMP ASSEMBLY GRN WIRE LEFT DOOR MIRROR LEFT VANITY LAMP PERSONAL LAMP PUDDLE LAMP RED WIRE RED/GRN WIRE RIGHT DOOR MIRROR RIGHT VANITY LAMP
