Infiniti QX55 I (2020-2024) A/t circuit

"N" POSITION SW "P" POSITION SW BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE CAN L CAN-H CHASSIS CONTROL MODULE COMPUTER DATA LINES SYSTEM CONTROL VALVE CVT FLUID TEMP SENS CVT FLUID TEMPERATURE SENSOR CVT UNIT (LEFT SIDE OF TRANSMISSION) D POSITION SW DOWN DRIVE MODE SWITCH FUSE 68 FUSE 82 FUSE, FUSIBLE LINK, RELAY BOX GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY 1 ENERGIZED IGN INPUT SPEED SENS IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) L POSITION SW LINE PRESS SOL VALVE LINE PRESSURE SOLENOID VALVE LT BLU WIRE LT GRN WIRE ORG/ WIRE OUT SPEED SENS PNK WIRE PPL PRI PRESS SENS PRI PRESS SOL VALVE PRI SPEED SENS PRIMARY PRESSURE SENSOR PRIMARY PRESSURE SOLENOID VALVE R POSITION SW RED WIRE SEC PRESS SENS SEC PRESS SOL VALVE SECONDARY PRESSURE SENSOR SECONDARY PRESSURE SOLENOID VALVE SELECT SOL VALVE SELECT SOLENOID VALVE SENS GND SENS PWR SPLY TAN WIRE TCC SOL VALVE TCM (TRANSMISSION CONTROL MODULE) TORQUE CONVERTER CLUTCH SOLENOID VALVE WHT WIRE YEL WIRE

BCM (BODY CONTROL MODULE) (LEFT SIDE OF DASH) BLK WIRE BLU WIRE BRAKE PEDAL ASSEMBLY) BRN WIRE CAN L CAN-H COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM FUSE 39 FUSE 49 FUSE 50 FUSE 53 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY-2 ENERGIZED IN SPD SENS INPUT SPEED SENSOR LT GRN WIRE ORG/ WIRE OUT SPD SENS OUTPUT SPEED SENSOR PADDLE SHIFTER PNK WIRE PPL PRIMARY SPD SENS PRIMARY SPEED SENSOR RED WIRE SENS GND SENS PWR SPLY SHIFT DOWN SWITCH SHIFT UP SWITCH STARTING/CHARGING SYSTEM STEERING COLUMN ASSEMBLY STOP LAMP SWITCH TRANSMISSION RANGE SWITCH (TOP OF TRANSMISSION) UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) WHT WIRE YEL WIRE
